10
www.howdens.com
LAM1114 4 Burner Premium Gas Hob
560mm
≥50mm
595mm
510mm
480mm
Safety Zone
Safety Zone
≥ 170mm
600mm (min)
≥ 170mm
+2
- 0
+2
- 0
Mains connection
Front
Gas connection
Wall
Minimum
space to wall
Minimum space
to splashback
Minimum space to
quartz splashback
+Splashback
+Quartz Splashback
≥70mm ≥70mm ≥70mm
Minimum distances to wall / splashback
Safety Zone:
Minimum of 170mm to any
vertical surface to the left
or right of the hob.
As a result of heat testing, the dimensions shown
below must be strictly adhered to in order to
ensure safe operation of the appliance.
Gas Safety
A gas pressure drop test (gas soundness / tightness test) on the respective gas meter should be performed
in accordance with relative gas safe standards by a registered gas safe engineer, to ensure there is an
acceptable leakage rate in the full system. If this test highlights an unacceptable leakage rate, then further
investigation into the source of the leak must be carried out and resolved.
