EN
25
SWITCHING OFF THE DEVICE
The device can be switched o at any
time by pressing the general on/off
touch key (1). In standby mode an
H will appear in the zones that are hot.
The rest of the displays will not light up.
Double burner hot plate
(Depending on model)
If your cooker has this option, the
double burner hot plate offers the
possibility of using the inside ring or
also, in addition, the outside one,
depending on the size of the pot or pan.
SWITCHING ON THE DOUBLE HOT
PLATE
1 The related hot plate must be selected.
2 Select the desired power (from 1 to
9) using the touch key or (4/5).
3 Press the double hot plate touch key
(6) to activate the double burner.
When the double zone will be activated,
double zone indicator (8) light on.
SWITCHING OFF THE DOUBLE
HOT PLATE
1 The key, by which its double burner
hot plate was switced on previously
is selected.
2 Press the double hot plate touch
key (6) to deactivate the double
burner. The double burner indicator
(8) will light o and the outer ring will
be deactivated
Locking of the touch
keys of the cooking hob
(depending on model)
To prevent undesired manipulation you
can lock the entire unit, except for the
on/o touch key, using the locking touch
key (7). This function is useful for child
safety. When the lock is activated, the
lock indicator light (9) comes on.
However, remember when the touch
control is on, the on/o touch key
(1)allows you to switch it o, even if
the lock is activated (the lock indicator
light (9) on).
On the other hand, if the touch control
is switched off, the locking function
does not allow the on/o touch key
(1) to be used.
To deactivate the locking function, press
the locking touch key (7) once again.
Lock indicator (9) light o and touch
control will be ready for use.
CHILD LOCK (depending on model)
The child lock is dierent and more
complicated than key lock. User can
activate key lock via one sensor. But
child lock need a sensor sequence.
The Child Lock is being used to prevent
children from turning on the hob.
Activating Child Lock :
1. The hob is switched on via (1) On/
O touch key,
2. Any zone should not be selected.
When any zone is not selected,
(5) Increase power touch key and
(4) decrease power touch key
and minus sensors is hold for 3
seconds at same time. At the end of
this period, a short buzzer sound is
heard
3. After buzzer signal , the (7) locking
touch key is touched (there is no
need to keep press for a long time)
and a long buzzer sound is heard
and the Child Lock will be activated
and all power display shows “L”.
During Child Lock, if user touch any
sensor (Main sensor included) , “L” will
ash on display.
Warning : Child lock status is not being
stored. If the energy of the hob is butted,
child lock status could not be preserved.
Deactivating Child Lock :
To be able to deactivate Child Lock, the
Child Lock should be activated before
and all power display show “L”
1. (5) Increase power touch key
and (4) decrease power touch
key and minus sensors is hold for 3
seconds at same time. At the end of
the this period, a short buzzer sound
is heard,
2. After buzzer signal , is touched to
the (7) locking touch key (there is
no need to keep press for a long
time) and a long buzzer sound is
heard and the Child Lock will be
de activated and “Indication will be
light o.
Flash Cooking
(Automatic cook start)
This function facilitates cooking as
you do not need to be present while it
is being done. The touch control pre-
programmes the chosen hot plate at
the maximum power and subsequently
lowers it to the desired power level
(which you have selected) after an
approximate amount of time (see
table 1).
Table 1
Selected
power
Automatic Cook
Start
Function
0 0
1 60
2 180
3 288
4 390
5 510
6 150
7 210
8 270
9 300
P (maximum) -
SWITCHING THE AUTOMATIC
COOK START FUNCTION ON
1 The hot plate must be selected.
2 Select power 9 and then press power
touch key (5).After using the touch
key you must lower the continuous
cooking power to the desired level,
(for example 6). When the automatic
cook function starts "A" indication
ashes with desired power level on
the display.
SWITCHING THE AUTOMATIC
COOK START FUNCTION OFF
After at least 10 seconds have elapsed
since the beginning of the automatic
cook start function:
1 The hot plate must be selected.
2 Press touch key (5) till the
indicator reaches level 9 and the
automatic cook start function will be
deactivated.
