Kramer Electronics Ltd.
VS-8FDxl - Protocol 3000
49
X-ROUTE
Functions
Permission
Transparency
Set:
X-ROUTE
End User
Public
Get:
X-ROUTE?
End User
Public
Description
Syntax
Set:
Send routing command to matrix
#X-ROUTESPOUT_signal_id,IN_signal_idCR LF
Get:
Get routing status
#X-ROUTE?SPOUT_signal_idCR LF
Response
Set / Get: ~nn@X-ROUTESPOUT_signal_id,IN_signal_idCR LF
Parameters
OUT_signal_id – OUT.SDI.<port_index>.VIDEO.<port_index> for further information see see
Signal ID Format on page 34).
IN_signal_id – IN.SDI.<port_index>.VIDEO.<port_index> for further information see see Signal
ID Format on page 34).
Notes
It is recommended to use the command #SIGNALS-LIST? To get the list of all signal IDs available in the
system and which can be used in this command.
Video 1 is the default port in this command and is implied even if not written:
#X-ROUTE OUT.SDI.5,IN.SDI.1 is interpreted as:
#X-ROUTE OUT.SDI.5.VIDEO.1,IN.SDI.1.VIDEO.1
Examples
#X-ROUTE OUT.SDI.5.VIDEO.1,IN.SDI.1.VIDEO.1
~01@X-ROUTE OUT.SDI.5.VIDEO.1,IN.SDI.1.VIDEO.1
#X-ROUTE? OUT.SDI.5.VIDEO.1
~01@X-ROUTE OUT.SDI.5.VIDEO.1,IN.SDI.1.VIDEO.1
Reduced form :
#X-ROUTE OUT.SDI.5,IN.SDI.1
~01@X-ROUTE OUT.SDI.5.VIDEO.1,IN.SDI.1.VIDEO.1
K-Config Example
Route port 1 (input) to port 8 (output):
“#X-ROUTE OUT.SDI.8.VIDEO.1,IN.SDI.1.VIDEO.1”,0x0D
