Kramer Electronics Ltd.
VS-8FDxl - Protocol 3000
48
VMUTE
Functions
Permission
Transparency
Set:
VMUTE
End User
Public
Get:
VMUTE?
End User
Public
Description
Syntax
Set:
Set enable/disable video
on output
#VMUTESPoutput_id,flagCR
Get:
Get video on output
status
#VMUTE?SPoutput_idSP CR
Response
Set / Get: ~nn@VMUTESPoutput_id,flagCR LF
Parameters
output_id – 1 (Port 1), 2 (Port 2), 3 (Port 3), 4 (Port 4), 5 (Port 5), 6 (Port 6), 7 (Port 7), 8 (Port 8)
flag – 0 (unmute), 1 (mute), 2 (blank video)
K-Config Example
Disable the video output on Port 2:
“#VMUTE 2,0”,0x0D
X-LONG-REACH
Functions
Permission
Transparency
Set:
X-LONG-REACH
End User
Public
Get:
X-LONG-REACH?
End User
Public
Description
Syntax
Set:
Set extra range (long reach) mode
for SDI ports
#X-LONG-REACHSPport_id,stateCR LF
Get:
Get extra range (long reach) state
configuration on any port
#X-LONG-REACH?SPport_idCR LF
Response
Get: ~nn@X-LONG-REACHSPport_id,stateCR LF
Parameters
port_id – <direction_type>.<port_type>.<port_index> for further information see Port ID Format
on page 33.
state – OFF, ON (not case sensitive)
Notes
Some devices support extra range (long reach) mode, used in HDBT and SDI applications.
Use the command #PORTS-LIST? to list all port IDs available in the system.
Example
#X-LONG-REACH IN.SDI.1,OFF
~01@X-LONG-REACH IN.SDI.1,OFF
#X-LONG-REACH? IN.SDI.1
~01@X-LONG-REACH IN.SDI.1,OFF
K-Config Example
Set port 1 (configured as input) long-reach mode to on:
“#X-LONG-REACH IN.SDI.1,ON”,0x0D
