Kramer Electronics Ltd.
VS-8FDxl - Protocol 3000
43
PRST-RCL
Functions
Permission
Transparency
Set:
PRST-RCL
End User
Public
Get
-
-
-
Description
Syntax
Set:
Recall saved preset list
#PRST-RCLSPpresetCR
Get:
-
-
Response
~nn@PRST-RCLSPpresetCR LF
Parameters
preset – preset number: 1 (Port 1)… 8 (Port 8)
K-Config Example
Recall preset 1:
“#PRST-RCL 1”,0x0D
PORT-DIRECTION
Functions
Permission
Transparency
Set:
PORT-DIRECTION
End User
Public
Get:
PORT-DIRECTION?
End User
Public
Description
Syntax
Set:
Set port direction for video port
#PORT-DIRECTIONSPport_index,directionCR LF
Get:
Get port direction for video port
#PORT-DIRECTION?SPport_index,directionCR LF
Response
Set / Get: ~nn@PORT-DIRECTIONSPport_index,directionCR LF
Parameters
port_index – port number from the front panel (1-8)
direction – IN (input), OUT (output)
Notes
This command defines the direction of a bidirectional port.
Then routing is possible between them, use X-ROUTE as following:
#X-ROUTE OUT.SDI.5,IN.SDI.1
~01@X-ROUTE OUT.SDI.5.VIDEO.1,IN.SDI.1.VIDEO.1
Example
Set:
#PORT-DIRECTION 5,OUT ~01@PORT-DIRECTION 5,OUT
#PORT-DIRECTION 1,IN ~01@PORT-DIRECTION 1,IN
Get:
#PORT-DIRECTION? 5 ~01@PORT-DIRECTION 5,OUT
#PORT-DIRECTION? 1 ~01@PORT-DIRECTION 1,IN
K-Config Example
Set the direction of port 1 to IN:
“#PORT-DIRECTION 1,IN”,0x0D
