Je bekijkt pagina 23 van 32
KRAMER: SIMPLE CREATIVE TECHNOLOGY
Operating the VS-48HDxl
20
7 Operating the VS-48HDxl
You can operate your VS-48HDxl using the:
Front panel buttons
RS-232/RS-485 serial commands transmitted by a PC, touch screen
system, or other serial controller
Kramer RC-IR2 Infrared Remote Control Transmitter
Infrared remote extension cable transmitter
ETHERNET
7.1 Switching OUT-IN Combinations
Section 7.1.1 describes how to switch OUT-IN combinations and section 7.1.2
how to switch OUT-IN combinations in the dual link mode.
Note that:
The OUTPUT button color changes during routing according to the input
button color: red (for standard definition) or blue (for high definition)
If no INPUT is connected to an OUTPUT, that OUTPUT button will not
illuminate
If a source is connected to an INPUT, that INPUT button will illuminate
7.1.1 Switch OUT-IN Combinations
To switch an input to an output via the front panel buttons
1
, in the AT ONCE
mode (see section 7.2), do the following:
1. Press an OUTPUT button from 1 through 8, or ALL.
The selected OUTPUT button illuminates brightly, as does the 7-segment
display.
2. Press an INPUT button from 1 through 4 or OFF
2
.
The selected input switches to the selected output, and that input button
illuminates brightly. The digits displayed in the 7-segment display change as
appropriate.
1 For details of how to route an input to an output using the REMOTE connector, see section 6.9
2 For immediate switching
