KRAMER: SIMPLE CREATIVE TECHNOLOGY
Your VP-411DS 4x1 Automatic UXGA / Audio Switcher
6
Figure 2 and Table 2 define the underside of the VP-411DS:
Figure 2: VP-411DS 4x1 Automatic UXGA / Audio Switcher Underside
Table 2: VP-411DS 4x1 Automatic UXGA / Audio Switcher Underside Features
# Feature Function
1 PROGRAM / NORMAL
Switch
Set to NORMAL for normal operation (default), or set to PROGRAM to
upgrade to the latest Kramer firmware via RS-232 (see Section
6)
2 Vs and Hs Switch
(from 1 to 4)
Slide the switch to NORMAL for standard sync detection
1
4.1 Using the IR Transmitter
Slide the switch to KR-ISP™ for crisp technology
You can use the RC-IR3 IR transmitter to control the machine via the built-in IR
receiver on the front panel or, instead, via an optional external IR receiver
2
. The
external IR receiver can be located 15 meters away from the machine. This distance
can be extended to up to 60 meters when used with three extension cables
3
Before using the external IR receiver, be sure to arrange for your Kramer dealer to
insert the internal IR connection cable
9F
4
with the 3.5mm connector that fits into the
REMOTE IR opening on the rear panel. Connect the external IR receiver to the
REMOTE IR 3.5mm connector.
1 By default, both switches are set to NORMAL
2 Model: C-A35M/IRR-50
3 Model: C-A35M/A35F-50
4 P/N: 505-70434010-S
