Kramer Electronics Ltd.
MTX3-88-HSA – Operating MTX3-88-HSA via Front Panel Buttons
18
Switching Modes
Use the front panel buttons for the following switching modes:
• Press VIDEO to switch the video signal of a selected input to the selected output.
• Press D-AUDIO (HDMI embedded audio signal) to switch the digital audio signal of a
selected input to the selected output.
• Press A-AUDIO (analog signal on 5-pin terminal block) to switch the analog audio
signal of a selected input to the selected output.
• Press VIDEO + D-AUDIO simultaneously to switch the video and digital audio signals
of a selected input to the selected output.
• Press VIDEO + A-AUDIO simultaneously to switch the video and analog audio signals
of a selected input to the selected output.
• Press PATTERN to switch a pattern signal (selected by the input buttons) to the
selected output.
• Press ARC and then an input button to set that input source to ARC.
Copying EDID
You can copy the EDID to an input from a connected output or use the default EDID.
To set the input port EDID via the front panel buttons
To set the input port using the output monitor EDID:
1. Press EDID. The EDID button LED lights, indicating the EDID operation state: all input
indicators off and all output indicators off.
2. Press the corresponding IN button and the button LED flashes: multiple IN buttons can
be selected simultaneously.
3. Press an output button the button LED lights.
4. Press Lock. The LOCK button LED lights and the EDID LED flashes for about 3-5
seconds to copy output monitor EDID to the selected input port.
5. The setting was successful and the unit returns to the VIDEO switch interface.
To set input port using default EDID:
1. Press EDID. The EDID button LED lights, indicating the EDID operation state: all input
indicators off and all output indicators off.
5. Press the corresponding IN button and the button LED flashes: multiple IN buttons can
be selected simultaneously.
6. Press LOCK button. The LOCK button LED lights and the EDID LED flashes for about 3-
5 seconds to copy the default EDID to the selected input port.
7. The setting was successful and the unit returns to the VIDEO switch interface.
