Kramer Electronics Ltd.
MTX3-88-HSA – Operating MTX3-88-HSA via Front Panel Buttons
12
Press
ALL (instead of an output button) to route the selected input to all the outputs.
Routing Analog Audio
The A-AUDIO button on the MTX3-88-HSA front panel enables to route either the analog
audio input signals or the HDMI embedded audio signals to the balanced stereo analog audio
outputs.
To switch an HDMI digital audio input to an analog output:
1. Press twice A-Audio button.
The button flashes (HDMI audio input to balanced audio output mode).
2. While A-AUDIO flashes, select an OUT button. The button illuminates (OUT 5 ~ OUT 8
button/light is not valid).
If the signal source of this channel audio is from HDMI audio, the corresponding HDMI IN
button illuminates.
3. Press the corresponding IN 1~IN 8 button, or the OFF button, and switch the output to
the corresponding channel immediately.
When switching you can also press:
ALL (instead of an output button) and then an input button to route the selected input to all
the outputs.
To switch an analog audio input to an analog output:
1. Press A-AUDIO button. The button illuminates (OUT 5 ~ OUT 8 button/light is not valid).
2. While A-AUDIO is ON, select an OUT button (for example, 3) and then an IN button (for
example, 4). Analog input 4 is routed to balanced stereo audio output 3.
When switching you can also press:
ALL (instead of an output button) and then an input button to route the selected input to all
the outputs.
Routing an Audio Input to the Digital HDMI Output
The D-AUDIO button on the MTX3-88-HSA front panel enables to route either the analog
audio input signals or the HDMI embedded audio signals to the HDMI outputs.
Generally, digital routing is enabled by pressing D-AUDIO:
When it is illuminated, the HDMI input embedded audio is the audio source.
When it flashes, the analog audio input is the audio source.
To switch an HDMI audio input to a digital output:
1. Press D-AUDIO.
