English

Size - A5

J

Fan opening

K

Castors

L

Wall duct with cap

M

Drainage hose

N

Exhaust adapter

O

Exhaust hose

P

Wall adapter

Q

Flat adapter

R

Battery (R03/AAA, 2x)

S

Screw (x4)

T

Wall plug (x4)

Installation

Placement

When choosing an installation place, consider

the following points:

• Observe all safety warnings!

• Ensure the minimum surrounding distance

in every direction of 30 cm and 100 cm to

other electrical products.

• Keep a surrounding distance of minimum

50cm around the outside of the exhaust

wall outlet and protect it from entering

objects and moisture.

• Make sure the wall behind the product is

an exterior wall not a divider and the drill

holes can be made in a safe way, and are not

obstructed by hidden objects in the wall.

• Ensure that a suitable power outlet is within

reach at the desired location and remains

accessible after installation.

• Consider that during dehumidifying

operation water is collected inside the

product, which must be continuously drained

through a connected drainage hose into a

suitable container or a nearby drain.

• Ensure there are no obstacles obstructing

the airflow.

Note:

If the product has been transported in a

horizontal position, it must not be plugged

in for 24 hours, in order to avoid damages of

the cooling system.

Air exhaust

The exhaust hose and adaptor must be

installed or removed in accordance with the

usage mode:

• COOL, AUTO mode: install exhaust hose

• FAN, DEHUMIDFY mode: remove exhaust

hose

Wall mounting (Part: N, O, P)

Fig.

1

Screw the wall adapter and exhaust

adapter onto each side of the exhaust

hose. Connect the exhaust adapter to

the air exhaust of the product.

IM_KAC9022W-WLAN_211125_V05_HR.indb 44 25/11/2021 11:24 AM
