45
English
Operation
Fig.
5
Switching on/o
The product can only be switched on
or into Standby. Unplug in order to
disconnect from the mains.
Press the on/o button or the ON/
OFF button to switch the product on or
into standby.
Note:
• After a power break or when the product
is switched into standby and on again in
a short time, the refrigerating compressor
will resume work after 3 minutes (delayed
start). This is to prevent the cooling circuit
from damages.
• If the product is tilted over, switch it into
standby and unplug immediately. Wait
at least 2 hours before operating the
product again to avoid damages on the
refrigerating circuit.
• Always switch the product into standby
before unplugging.
Remote control
Fig.
6
Remove the battery compartment cover.
Insert 2 batteries (type R03/ AAA) while
paying attention to the correct polarity.
Close the battery compartment. Using
the control panel and the remote control
alternately might lead to a misalignment
of the product and the information
displayed on the remote control.
Note:
• Press any button on the remote control
and the product adopts the current
setting from the remote control.
• The signals of the remote control will
be transmitted with a short delay after
a button is pressed. This process is
indicated by the appearing
symbol on
the remote control display.
• Every press of a button on the remote
control will illuminate the display on the
remote control for a few seconds for
better visibility in the dark.
Fig.
2
Use the wall duct as pattern to mark the
hole spacing on the wall. Drill the holes
with a suitable power tool. Free the
holes from dust and mount the wall
duct using the supplied screws and
plugs. Connect the wall connector to
the wall adaptor.
Note:
• The exhaust hose can be expanded and
compressed, but for optimal performance,
keep the exhaust length to a minimum.
• Do not extend the exhaust hose.
• Avoid over-bending.
• Observe the decommissioning instructions
in the respective section, if the product is
not to be used for a longer period of time.
Window installation (Part: N, O, Q)
Fig.
3
The exhaust hose can be attached to
an open or tilted window alternatively.
Screw the window outlet adapter onto
the open end of the exhaust hose.
Drainage hose
The drainage hose is used to drain water from
the upper drain outlet.
Fig.
4
Remove the rubber plug from the upper
drainage outlet and slide the drainage
hose as far as possible onto the outlet.
Lead the other end of the drainage hose
into a suitable container or a nearby drain.
Note:
• Depending on the set modus the water
is either drained directly or collected in an
internal tank. Drain the water respectively.
• Attach the open end of the drainage hose
to the drainage hose holder, when not in
use.
• Always cover the drain outlets when not
in use.
• Observe the decommissioning
instructions in the respective section, if
the product is not to be used for a longer
period of time.
