43
English
To avoid the generation of waste, please prefer
batteries with a longer life or rechargeable
batteries. To avoid littering, please do not leave
batteries in public space but collect and return
them for recycling.
Delivery Content
1 x Portable Air conditioner
1 x Remote Control
1 x Wall duct with cap
1 x Drainage hose
1 x Exhaust adapter
1 x Exhaust hose
1 x Flat adapter
1 x Wall adapter
4 x Wall plugs
4 x Screws
2 x Batteries (Type R03/AAA)
1 x User manual
Technical data
Power supply : 220 - 240 V~ 50 Hz
Maximum power input : 1160 W/ 5.65 A
Protection class : I
Fuse : 250 V T3,15AL
Cooling capacity : 9000 Btu/h
Refrigerant : R290/ 0.19 kg
Frequency range : 2402 - 2480 MHz (BT)
2412 - 2472 MHz (WIFI)
Max RF power : 6,6 dBm (BT)
18.1 dBm (WIFI)
Declaration of conformity
Hereby, Imtron GmbH declares that the radio
equipment type KAC 9022 W WLAN/ KAC
9022 B WLAN/ KAC 9022 W CH WLAN/
KAC 9022 B CH WLAN is in compliance with
Directive 2014/53/EU. The full text of the EU
declaration of conformity is available at the
following internet address:
http://www.koenic-online.com/nc/suche.html
Controls and components
A
Remote control
1. Remote control emitter
2. Display with function indicators
3. Power switch ON/OFF
4. Mode selection button MODE
5. Fan speed button FAN
6. Comfort mode button SLEEP
7. Oscillation button SWING
8. Battery compartment with lid
9. FOLLOW ME button
10. Display/indicator ON/OFF button LED
11. Timer button TIMER OFF
12. Timer button TIMER ON
13. Pre-programmed button SHORT CUT
14. Temperature up/down
/
B
Recessed handle (on both sides)
C
Air exhaust
D
Power cord and plug (not shown)
E
Lower drain outlet
F
Lower air filter
G
Upper drain outlet
H
Upper air filter
I
Control panel
1.
Comfort mode indicator
2.
Fan speed indicator
3.
Temperature unit indicator °C /°F
4.
Display
5.
FOLLOW ME indicator
6.
Auto/Cool mode indicator
7.
Dehumidifying/Fan mode indicator
8.
Timer ON/OFF indicator
9. Oscillation button SWING / Wifi
button
10.
Timer program button TIMER
11.
Mode selection button MODE
12.
Temperature down/Decrease –
13.
Temperature up/Increase +
14.
Fan speed button FAN
15.
Comfort mode button SLEEP
16.
ON/OFF button
IM_KAC9022W-WLAN_211125_V05_HR.indb 43 25/11/2021 11:24 AM
