Je bekijkt pagina 21 van 34
Example: C310 with hotwire (0-30 m/s) – Current measurement: 2 m/s – New measurement: 8 m/s
The air velocity source being unstable, the user selects a strong integration. Integration: 7. The variation is lower than
10m/s, it is possible to apply the integration calculation formula.
Next displayed value: ((2 * 8) + (7 *2 ))/10 = 3 m/s.
➢ Press OK.
➢ Enter the security code then press OK.
➢ Go to the “Parameters” line then press OK.
➢ Go to “Probe 1” or “Probe 2” line (according to the channel of the air velocity/airow probe) then press OK.
➢ Go to “Air velocity integration” line then press OK.
➢ Use Up and Down arrows to select an air velocity integration then press OK.
The air velocity integration must be between 0 and 9.
3.6.2 Configure a CO
2
probe or a temperature/hygrometry probe
A CO
2
probe or a temperature/hygrometry probe must be connected to the transmitter.
Set the compensation in atmospheric pressure
➢ Press OK.
➢ Enter the security code then press OK.
➢ Go to the “Parameters” line then press OK.
➢ Go to “Probe 1” or “Probe 2” (according to the channel of the CO
2
probe) then press OK.
➢ Go to “Compensation” line then press OK.
➢ Go to “Atmo pressure” line then select the unit with the Up and Down arrows.
➢ Press OK.
➢ Enter a value. This value must be between:
• 0 and 4000 hPa
• 0 and 4000 mbar
• 0 and 3000.24 mmHg
• 0 and 10 000 m (altitude)
3.6.3 Configure a board
A pressure board must be connected to the transmitter.
For the air velocity/airow settings, the “Air velocity/airow” option must be activated.
Select the measuring device:
➢ Press OK.
➢ Enter the security code then press OK.
➢ Go to the “Parameters” line then press OK.
➢ Go to “Board” line then press OK.
➢ Go to “Air velocity/airow” line then press OK.
➢ Press OK on “Measure mean” line then use Up and Down arrows to select:
• Pitot tube L (coefcient: 1.0015)
• Pitot tube S (coefcient: 0.84)
• Debimo blades (coefcient: 0.8165)
• Coefcient of the element (free coefcient)
➢ Press OK.
Select the type of section: 3 selections are possible: rectangular or circular section or airow coefcient.
Congure the transmitter
21
