3.6.1 Configure an air velocity and airflow probe
An air velocity/airow probe must be connected.
Select the type of section:
➢ Press OK.
➢ Enter the security code then press OK.
➢ Go to the “Parameters” line then press OK.
➢ Go to “Probe 1” or “Probe 2” line (according to the channel of the air velocity/airow probe) then press OK.
➢ Go to “Type of section” line then press OK.
For a rectangular section:
➢ Select “Rectangular” with Up and Down keys then press OK.
The transmitter displays the necessary settings to perform for a rectangular section.
➢ Press OK on “Unit” line then select “mm” or “inch” whith Up and Down keys.
➢ Press OK.
➢ Go to “Length” line then press OK.
➢ Use Up/Down/Left/Right arrows to enter the length of the section then press OK.
➢ Go to “Width” line then press OK.
➢ Use Up/Down/Left/Right arrows to enter the width of the section then press OK.
Length and width of the section must be between 1 and 3000 mm.
For a circular section:
➢ Select “Circular” with Up and Down arrows then press OK.
The transmitter displays the necessary settings to perform for a circular section.
➢ Press OK on “Unit” line then select “mm” or “inch” with Up and Down keys.
➢ Press OK.
➢ Go to “Diameter” line then press OK.
➢ Use Up/Down/Left/Right arrows to enter the diameter of the section then press OK.
The diameter of the section must be between 1 and 3000 mm.
Enter a correction factor: this correction coefcient allows to adjust the transmitter according to data in air velocity of
the installation.
How to calculate it? For example, the air velocity in your section is 17 m/s and the transmitter displays 16.6 m/s. The
coefficient to apply is 17 / 16,6 it means 1.024.
➢ Press OK.
➢ Enter the security code then press OK.
➢ Go to “Parameters” line then press OK.
➢ Go to “Probe 1” or “Probe 2” line (according to the channel of the air velocity/airow probe) then press OK.
➢ Use Up/Down/Left/Right arrows to enter a correction factor then press OK.
The correction factor must be between 0.2 and 2.
Enter an integration in air velocity: The air velocity measurement element of the transmitter is very sensitive and
reacts to air velocity changes. When making measurements in unstable air systems, the air velocity measurement may
uctuate. The integration coefcient (from 0 to 9) makes an average of the measurement ; this helps to avoid any excessive
variations and guarantees a stable measurement.
New displayed value = [((10 - Coef.) x New Value) + (Coef. x Old value)] /10
20
Congure the transmitter
