20 English
2. Clean the dirty water tank and the cover by tap wa-
ter, and cleaning brush.
Illustration P
3. Alternatively, the dirty water tank can be cleaned in
the dishwasher.
4. Take the flat pleated filter and sponge filter out from
the dirty water tank cover.
5. Clean the flat pleated filter and sponge filter under
running water, and dry them completely, then rein-
stall them back to the dirty water tank.
Illustration Q
Cleaning the floor nozzle
ATTENTION
Damage due cleaning the roller with fabric softener
or using a clothes dryer
Damage to the microfibres
Do not use fabric softener when cleaning in a washing
machine.
Do not dry the roller in a clothes dryer.
ATTENTION
Material damage due to the loose roller
This may damage the washing machine.
Place the roller in a laundry net and load the washing
machine with extra laundry.
Note
In the case of heavy contamination or if parts such as
stones or splinters get into the suction head, it will need
to be cleaned. While the appliance is working, these
parts will cause a rattling noise or will block up.
1. Press the ON / OFF button.
The device switches off.
2. Step on the floor nozzle, and push the upper body to
upright position.
3. Press the floor nozzle cover release button and re-
move the floor nozzle cover.
Illustration R
4. Push the cleaning roller unlock button to the left and
pull it upwards to remove the cleaning roller.
Illustration S
5. Remove the side cover of the cleaning roller.
Illustration T
6. Clean the cleaning roller under running water or
wash them in a washing machine at max. 60 °C.
Illustration U
7. Place the roller on the storage holder on the parking
station to dry.
Illustration O
8. If there is debris on the floor nozzle cover, rinse it
under running water.
Illustration V
9. If there is debris inside the floor nozzle, clean the in-
side of the floor nozzle and the suction tube using a
tissue or the cleaning brush.
Illustration X
10. To install the cleaning roller, install the side cover
first, and put the cleaning roller onto the right wheel
axle and press it down. When you hear a "click", the
installation is complete.
Illustration W
11. Press the floor nozzle cover down until it audi
bly
cli
cks into place.
Illustration Y
Cleaning the charging and cleaning station
ATTENTION
Do not rinse the charging and cleaning station under
running water.
1. If there is debris on the charging and cleaning sta-
tion, wipe it with a wet cloth, avoiding the charging
pins.
2. If there is debris in the cleaning brush and cleaning
roller holder, remove the holder downwards and
clean it under running water.
Illustration Z
Cleaning and care agents
ATTENTION
Use of unsuitable detergents and care agents
The use of unsuitable detergents and care agents can
damage the device and loss of eligibility for warranty
claims.
Use only KÄRCHER detergents.
Take care to ensure the correct dosage.
Note
Use KÄRCHER detergent or care agents for floor clean-
ing as necessary.
Observe the manufacturer's dosing quantity recom-
mendations when dosing with detergent or care
agents.
To prevent foaming, fill the fresh water tank with wa-
ter first and then add the detergent or care agent.
To prevent the tank from overflowing, be sure to
leave enough space for the detergent or care agent
when filling with water.
Replace the battery
If the battery is damaged, contact KÄRCHER service to
purchase a new battery pack, and replace the old one.
ATTENTION
Do not remove the protective foil wrapped around the
battery pack.
When replacing the battery pack, make sure the device
is disconnected from the charging and cleaning station
and turned off.
When replacing the battery pack, avoid the high temper-
ature and high humidity environment, and do not install
the new battery pack with wet hands.
1. Remove the device from the charging and cleaning
station and make sure the device is turned off.
2. Remove the 6 screws on the battery pack cover by
a screwdriver.
Illustration AA
3. Remove the two screws on top and bottom of the
battery pack.
Illustration AB
4. Loose the battery pack from the bottom, and unplug
the two terminals on top of the battery.
Illustration AC
5. Unpack the new battery pack. Connect the terminals
on the top of the new battery pack, and secure the
battery into the battery compartment by two screws.
Illustration AD
6. Screw on the 6 screws to fix the battery pack cover.
Illustration AE
Troubleshooting guide
Malfunctions often have simple causes that you can
remedy yourself using the following overview. When in
doubt, or in the case of malfunctions not mentioned
here, please contact your authorised Customer Service.
