− 31 −
1. When the front and rear momentum of
the looper has been adjusted, move the
respective looper bases
!1
,
!2
and
!3
,
and readjust the front/rear positions
of the needles (
4
,
5
and
6
) and the
loopers (
1
,
2
and
3
).
2. When the above-mentioned adjust-
ments are carried out, the throat plate
!4
should be removed.
3. When the front and rear momentum
amount of the looper is small :
The amount of contact becomes large
between tips of the needles (
4
,
5
and
6
) and rear parts of the loopers (
1
,
2
and
3
) and this can be a cause of
needle tip being blunt.
4. When the front and rear momentum
amount of the looper is large :
The clearance becomes large between
tips of the needles (
4
,
5
and
6
) and
rear parts of the loopers (
1
,
2
and
3
) and this can be a cause of stitch
skipping.
(3) Adjustment of longitudinal movement of
the looper without differential feed
1) Loosen the setscrews
7
(4 pcs.) and remove the
cylinder side cover
8
.
2) Loosen the setscrew
!0
of the ball joint
9
with
a screwdriver, and adjust the forward/reverse
movement by moving the setscrew
!0
forward or
backward.
3) After adjustments, mount the cylinder side cover
8
,
and tighten the setscrews
7
.
™
When reducing the front and rear momentum
amount of the looper, move the ball joints
9
upwards.
™
When increasing the front and rear momentum
amount of the looper, move the ball joints
9
downwards.
Model without differential feed
Up-down
direction
!1
!2
!3
Right and left
directions
4
・
5
・
6
1
・
2
・
3
7
8
9
!0
