− 32 −
7. Adjustment of rear needle guard
(1)
Longitudinal adjustment of the rear needle guard
1) When the pulley is turned counterclockwise and
the rear needle guard
1
advances to the most
front position, it lightly touches the left needle
2
(If necessary, press it lightly so that all the needles
can be guarded.) and then tip of the front looper
3
passes.
When tip of the front looper
3
reaches the position
1.5mm apart from the left side of the left needle
2
while this front looper
3
moves in right direction,
the standard position is that the needle tip comes in
contact with the rear needle guard
1
.
2) The relationship between the middle needle
4
and
the rear looper
5
and between the right needle
6
and the middle looper
7
is also required to assume
the same conditions as (1) -1). above in standard
positioning.
3) Loosen the setscrew
8
and move the rear needle
guard
1
forward or backward to adjust.
4) After adjustments, tighten the setscrew
8
.
(2) Height adjustment of rear needle guard
1) The relationship between the middle needle
4
and
the rear looper
5
and between the right needle
6
and the middle looper
7
is also required to assume
the same conditions as (1) -1) above in standard
positioning.
2) Loosen the setscrew
9
and move the rear needle
guard base
!0
vertically to adjust the height.
3) After adjustments, tighten the setscrew
9
.
Longitudinal directions of rear needle guard
Vertical direction of rear needle guard
Longitudinal
directions
The clearance provided
between the blade point of
the looper and the needle
should be 0 to 0.05 mm.
1
1
3
8
1.5mm
Up-down
direction
2
・
4
・
6
3
・
5
・
7
4
6
2
5
7
3
1
Right and left
directions
WARNING :
Perform the work after turning OFF the power to prevent accidents caused by the abrupt start of the
sewing machine.
1. To change the stitch length, readjust-
ment of the front and rear positions is
also needed for rear needle guard
1
.
2. When the rear needle guard is adjusted,
recheck the non-presence of a clearance
between the respective needles (
2
,
4
and
6
) and the respective loopers (
3
,
5
and
7
). If any clearance is perceived,
readjust the related conditions.
3. Is a clearance is actually developed
between the respective needles (
2
,
4
and
6
) and rear needle guard
1
, this
can be a cause of needle breakage or
stitch skipping.
4. When rear needle guard
1
presses the
respective needles (
2
,
4
and
6
) too
much, this can be a cause of needle tip
being blunt.
2
1
3
9
!0
When the right side face of the
needle is aligned with the blade
point of the looper
Distance between
the needle guard
and the bottom
end of the needle
eyelet : 0.5 to 2
mm
