6 Assembly
Assemblethemastassemblytothebaseassemblyonaat,
level, and hard surface. Follow the steps below to properly
assemble the material lift.
The mast assembly is very heavy. When moving the
mast assembly into place and attaching to the base
assembly, use a forklift or hoist and at least two
people.
Before lifting and moving the mast assembly, make
sure the lift hook is securely fastened to the hook
bracket on the underside of the mast. See Section 3
Product Identication for hook bracket location.
1. After removing the base assembly from the crate, position
itonaat,level,andhardsurface.
2. Release the red mast/legs locking plate on the base by
liftingandrotatingtotheopenposition(seeFigure6-1).
Pivot legs out to their widest setting for maximum stability.
Do this by grasping the legs near the caster cylinders and
movingthelegsoutward.SeeFigure6-1.
6. Supportthesquaretubeandremovethemastpinfrom
the mast pivot bracket. Swing the square tube down so
itisperpendiculartothemast(seeFigure6-4).Reinsert
the mast pin through the mast pivot bracket and square
tube to lock the square tube in this position. Secure the
pin using the spring cotter pin.
3. Lock the legs in place by rotating the red mast/leg locking
plate back into place. Make sure it drops into the locked
position(SeeFigure6-2).
4. Lock all four wheel casters (see Section 7.10 LOCKING
CASTERS).
5. Place a lifting strap through the travel mode lift point on the
winchsideofthemastassembly(seeFigure6-3).Securely
attach the lifting strap to the overhead forks of a forklift
or a hoist with proper lifting capacity. Carefully raise the
mast assembly from the crate.
Figure 6-1: Pivot Legs to Widest Position
Figure 6-2: Mast/Legs Locking Plate in Locked Position
Figure 6-3: Travel Mode Lift Point
Figure 6-4: Positioning Square Tube
6.1 ATTACHING MAST ASSEMBLY TO
BASE ASSEMBLY
JET TOOLS • SKY25 SKYHYKER MATERIAL LIFT | 8
Continued
