15
LCD PANEL
Panel type IPS Series VA Series IPS Series IPS Series VA Series
Size 43 50 55 65 75
Backlight DLED
Brightness (Typical) 250cd/m² ± 10% 250cd/m² ± 10% 280cd/m² ± 10% 300cd/m² ± 10% 300cd/m² ± 10%
Contrast 1200:1 5000:1 1000:1 1000:1 5000:1
Dynamic Contrast Ratio (DCR) YES
Pixel Pitch (mm) 0.24 0.28 0.31 0.37 0.43
Resolution (H×V) 3840 x 2160
Aspect Ratio 16:9
Response Time 8ms 8ms 6ms 8ms 6ms
View Angles (CR>10) H:178° V:178°
Panel Surface Semi-Gloss
Display Colors
1.07B 1.07B 16.7M 16.7M 1.07B
Functions
HDCP HDCP 2.2
HDR10 YES
Interface and
Max Resolution
/Refresh Rate
HDMI 1
3840x2160
HDMI2.0
HDCP2.2 Compatible
HDMI 2
HDMI 3
USB
Playback of videos, still images, audio files, etc...
Functions such as loop playback and pause are possible.
Audio
Audio Output YES
Speakers (Typical) 8Wx2 10Wx2
Power
Power Consumption (W)
Max ≤ 75
Standard ≤ 44
Standby ≤ 0,5
Max ≤ 115
Standard ≤ 56
Standby ≤ 0.5
Max ≤ 150
Standard ≤ 74
Standby ≤ 0,5
Max ≤ 185
Standard ≤ 117
Standby ≤ 0,5
Max ≤ 290
Standard ≤ 152
Standby ≤ 0,5
AC Power Range (Hz) AC 100V 50/60
Operating
/Condition
Temperature (℃) 0～45
Humidity (%) 10 ~ 85
Physical
Dimensions with Stand included
(width x height x depth mm)
965x615x205 1125x706x255 1244x782x254 1466x906x295 1690x1027x321
Packaging Dimension
(width x height x depth mm)
1028x632x120 1185x723x138 1308x807x122 1555x920x170 1897x1165x250
Weight Net (kg) 6.8 8.3 11.2 18.2 27.6
Weight Gross (kg) 8.3 10.8 14.1 23.2 37.9
VESA Mount (mm) 200 x 200mm 200 x 200mm 200 x 200mm 400 x 400mm 400 x 300mm
Accessories
HDMI 2.0 Cable YES
Remote control YES
User Manual YES
Compability Windows / mac OS YES
*Please note that the design, specications, and appearance of the product may be changed without notice for
product improvement.
*If there is a discrepancy between the information provided and the actual product, the actual product will take
precedence.
TECHNICAL SPECIFICATION
