94
Condition Cause Reference
The machine does
not run.
1. The machine is not plugged in.
2. Thread is caught in the hook race.
3. The presser foot lifter is not lowered.
Page 7
Page 86
Page 10
The embroidery
patterns are
distorted.
1. The needle thread tension is too strong.
2. Stabilizer is not used for sewing stretch and very ne fabrics.
3. The hoop tightening screw is too loose.
4. Something is caught between the carriage and the
carriage arm
.
5. The carriage arm is hitting something around the machine.
6. The fabric is caught or trapped when sewing embroidery.
7. The embroidery hoop is hitting something around the machine.
8. The embroidery foot is caught by a jump thread.
Page 11
Apply a stabilizer.
Page 27
Page 21
Page 21
Stop the machine and
free the fabric.
Page 21
Trim the jump thread.
Auto thread
cutting failed.
1. Threads are caught in the auto thread cutter device. Page 86
Keys on the visual
touch screen and
touch panel keys
do not work.
1. The key position is out of alignment. Page 77
Visual touch
screen is not
clear.
1. The screen brightness is not adjusted properly. Page 76
Visual touch
screen swells.
1. The machine has been exposed to a high-humidity and high-
temperature area.
Use and store the
machine in cool dry
place.
The bobbin thread
remaining sensor
does not work;
There is no signal
sound when the
bobbin thread has
run out and the
machine does not
stop sewing.
1. The bobbin thread remaining sensor is turned off.
2. Lint has been collected around the bobbin thread detecting
sensor.
3. A bobbin other than the “J” plastic bobbin is used.
Page 80
Page 86
Page 14
The message
“Bobbin thread
is not sufcient.”
appears and the
machine stops,
although there is
enough thread
wound on the
bobbin.
1. A strong light such as a white light bulb or LED light illuminates the
area around the hook cover on the needle plate.
Do not shine the area
around the hook cover
on the needle plate
with strong light.
The USB ash
drive is not read.
1. Format setting of the USB ash drive is not correct.
2. The USB ash drive is malfunctioning.
Pages 95-96
Replace the USB ash
drive.
It is not abnormal for a faint humming sound to be heard from the internal motors.
The visual touch screen and function key area may become warm after several hours of continuous use.
