Je bekijkt pagina 47 van 56
47
www.janitza.com 800-CT8-LP module
General
Net weight (with terminals) approx. 73g (0.16lbs)
Device dimensions (without connection terminals)
W=18mm(w=0.71in), H=90mm(h=3.54in),
D=76mm(d=2.99in)
Width of the device in horizontal pitches 1 HP (1 HP = 18 mm / 0.71 in)
Mounting orientation As desired
Fastening/mounting -
Suitable DIN rails - (35mm / 1.38in)
· TS 35/7.5 according to EN60715
· TS 35/10
· TS 35/15 x 1.5
Protection against foreign matter and water IP20 according to EN60529
Impact resistance IK07 according to IEC 62262
Environmental conditions during operation
The module
· Must only be operated with suitable basic devices (see “Tab. suitable basic devices” on p. 2).
· Is for weather-protected and stationary use.
· Fulfills operating conditions according to DIN IEC 60721-3-3.
· Has protection class II according to IEC 60536 (VDE 0106, part 1), a ground wire connection is not required!
Working temperature -10°C (14°F) to +55°C(131°F)
Relative humidity 5 to 95% at 25°C (77°F), no condensation
Pollution degree 2
Ventilation No forced ventilation required
Supply voltage Via basic device
Transport and storage
The following specifications apply for devices transported and stored in the original packaging.
Free fall 1m (39.37in)
Temperature K55: -25 °C (-13 °F) to +70 °C (158 °F)
Relative humidity 0 to 95% at 25°C (77°F), no condensation
13. Technical data
Current measurement
Measurement via low-power current transformers with a secondary
voltage of
0-400mV
Channels
8 (2x4)
· 2 systems - L1, L2, L3, N
· Single channels
Input impedance per channel 230kΩ
Nominal input signal of the module 0..400mV
Crest factor 1.8
Overload for 1s 1V
Resolution 16 bit
Sampling frequency 6.8kHz
Frequency of the
fundamental oscillation
40Hz .. 70Hz
Harmonics 1...15 (odd only)
13.1 Technical specifications
