800-CT8-LP module www.janitza.com
Module 800-CT8-LP LEDs
Tx (send data)
Blink "orange" during operation and indicate cyclic data exchange.
Rx (receive data)
P (power – power supply) Lights "green" if the supply of power via the JanBus interface is correct.
E (error – initialization and malfunction) Lights "red" when initializing/starting the device and in the event of a fault.
Interface and energy supply
JanBus (proprietary) · Via bus connector
Supply voltage (via JanBus interface) 24V
Connection capacity of the terminals - Spring terminals (push-in terminals)
Connectible conductors. Only connect one conductor per terminal point!
Single core, multi-core, fine-stranded (min. - max.) 0.14mm
2
- 1.5mm
2
, AWG 26-16
Wire ferrules with collar *
to DIN 46 228/4, (min.-max.)
0.25mm
2
- 1mm
2
, AWG 22-17
Wire ferrules without collar
to DIN 46 228/1, (min.-max.)
0.25mm
2
- 1.5mm
2
, AWG 22-16
Wire ferrules:
- Contact sleeve length **
- Strip length
8 - 12mm(0.31 - 0.47in)
10 - 12mm(0.39 - 0.47in)
* ... Applies to wire ferrules with a maximum plastic collar outer diameter of up to 4.5mm (0.18in).
**.. Depending on the type of wire ferrules used (wire ferrules manufacturer).
