Je bekijkt pagina 17 van 60
www.janitza.com
17
800-CT24 module
INFORMATION
This user manual describes modules and provides
information on operating the modules via a basic
device.
Please refer to the user manual for the basic device for
information on operating, configuring and reading out
expansion modules.
The GridVis
®
software has an online help with
tutorials.
A list of parameters and Modbus addresses with
data on your basic device with module can be
found in the download area at www.janitza.com.
3.10 Operating concept
For meter and module topologies, modules have
the following options for configuring or reading out
measured values:
· Display and buttons on the basic device (user
interface).
· The GridVis network analysis and programming
software
®
for programming and analysis of data.
· Via the RS-485 interface or Ethernet interface.
· If applicable Web server with device homepage
of the basic device for analysis and configuration
of the essential measurement device and module
parameters (see usage information for the basic
device).
· If necessary, via an HMI (human machine interface)
integrated in the project.
The modules can be used to realize measurement
device and module topologies with a flexible ar-
rangement of the DIN rails (for examples of this,
see Sect. “8. Module communication / PC connec-
tion” on p. 32). For the operation of the devices,
components and modules integrated in your meter
and module topology, please refer to the respective
additional usage information.
3.11 GridVis
®
network analysis and programming
software
With the GridVis
®
software, you have the perfect tool
for programming, reading out and visualizing mea-
surement data (download at www.janitza.com).
Performance characteristics of the GridVis
®
soft-
ware
· Configuration of the basic device and the modules
of your meter and module topology.
· Graphic display of measured values.
· Report functions.
· Online help and tutorials.
Connections to the PC (GridVis
®
software)
Information on connections for communication
between the PC and the basic device (with modules)
can be found in the usage information of the basic
device.
