www.janitza.com
23
Module800-CON-RJ45
6.2 Data transfer with 800-CON-RJ45 module
Check the maximum number of slots on your ba-
sic device (see „Tab. Suitable basic devices“ on p.
2).To use all available slots of a basic device, the
following JanBus measurement device and module
topologies, for example, can be realized using the
800-CON-RJ45 transfer module:
1. A JanBus topology consisting of 1-slot modules
until the maximum number of slots of the basic
device is exhausted (e.g. digital input module
800-DI14, current measuring module 800-CT8-A,
current measuring module 800-CT8-LP).
2. A combined JanBus topology consisting of
1-slot and X-slot modules until the maximum
number of slots of the basic device is exhausted
(e.g. a combination of 1-slot and 3-slot modules,
such as the 800-CT24).
3. One JanBus topology 800-CT24, for example,
consisting of several 3-slot modules until the
maximum number of slots of the basic device is
exhausted (e.g. a JanBus topology with 3 current
measuring modules of the type 800-CT24, which
together occupy 9 slots).
INFORMATION
System limits:
· The maximum bus length (JanBus - proprietary)
for setting up measurement device and module
topologies can be found in Sect. “8. Technical data”
on p. 29.
· Use a commercially available RJ45 cable (RJ45
patch cable) for trouble-free JanBus communi-
cation in your measurement-device and module
topology.
· The 3 following measurement-device and module
topologies with JanBus communication are exam-
ples! Before mounting, please check the number
of suitable modules for your measurement-de-
vice and module topology based on the respec-
tive usage information.
· Do not exceed the maximum number of module
slots of the basic device (the 800-CON-RJ45
transfer module does not occupy a slot)!
· The scope of delivery of the 800-CON-RJ45 mod-
ule can be found in the user manual for the module.
