07610-004-66-53-F
6
28 3/4
[731 mm]
8 5/16
[211 mm]
Distance from
Wall to Rear
Rack Rail
8 5/16
[211 mm]
Distance from
Wall to Left
Rack Rail
4 1/4
[108 mm]
MIN
4 1/4
[108 mm]
MIN
28 3/4
[731 mm]
8 5/16
[211 mm]
Distance from
Wall to Rear
Rack Rail
4 1/4
[108 mm]
MIN
20 1/2
[521 mm]
OPENING
20 1/2
[521 mm]
OPENING
Control Panel
1 1/4
[32 mm]
1 ± 1/4
[25 ± 6 mm]
20 1/2
[521 mm]
OPENING
5
[127 mm]
5 3/8
[137 mm]
CORNER INSTALLATION
STRAIGHT-THROUGH INSTALLATION
SPECIFICATIONS
TABLE DIMENSIONS
Notch required for corner insallation
on DynaStar and DynaStar VER
only. See False Panel/Corner
Installation Instructions.
DynaStar
False Panel Option
05700-004-67-60
False Panel/Corner
Installation Instructions
HH-E
False Panel Option
06401-004-89-11
False Panel/Corner
Installation Instructions
DynaStar shown.
