07610-004-66-53-F
7
OPERATING CAPACITIES
SPECIFICATIONS
Always refer to the machine data plate for specic electrical and water requirements.
The material provided on this page is for reference only and may change without notice.
NOTICE
i
PERFORMANCE/CAPABILITIES
Operating Capacity:
DynaStar/NB/HH-E/HH-E NB
Racks per Hour without Load Time 62
Racks per Hour with Load Time 57
Dishes per Hour without Load Time 1550
Dishes per Hour with Load Time 1425
Glasses per Hour without Load Time 2232
Glasses per Hour with Load Time 2052
DynaStar VER/HH-E-VER
Racks per Hour without Load Time 40
Racks per Hour with Load Time 38
Dishes per Hour without Load Time 1000
Dishes per Hour with Load Time 950
Glasses per Hour without Load Time 1440
Glasses per Hour with Load Time 1368
Minimum Operating Cycle (seconds):
Cycle 1 Wash Time 40
Cycle 2 Wash Time 90
Cycle 3 Wash Time 220
Rinse Time (Econo) 11
Rinse Time (Turbo Option) 14
Dwell Time 7
Cycle 1 Total Time 58
Cycle 2 Total Time 108
Cycle 3 Total Time 238
VER Condensate Removal 30*
Tank Capacity (gallons/liters):
Wash Tank 8.0/30.3
Rinse Tank 1.66/6.3
*With Smart Vent o. See Smart Vent section.
WATER REQUIREMENTS
DynaStar/HH-E
Wash Temperature (Minimum) 150 °F/66 °C
Rinse Temperature (Minimum) 180 °F/83 °C
Inlet Water Temperature 110 °F/44 °C
Flow Pressure (PSI) 15–65
Water Line Size (NPT) 1/2”
Drain Line Size (NPT) 1 1/2”
DynaStar NB/HH-E NB
Wash Temperature (Minimum) 150 °F/66 °C
Rinse Temperature (Minimum) 180 °F/83 °C
Inlet Water Temperature 180 °F/83 °C
Flow Pressure (PSI) 10 ± 2
Water Line Size (NPT) 1/2”
Drain Line Size (NPT) 1 1/2”
DynaStar
VER/HH-E VER
Wash Temperature (Minimum) 150 °F/66 °C
Rinse Temperature (Minimum) 180 °F/83 °C
Inlet Water Temperature 40–90 °F/4.4–32.2 °C
Flow Pressure (PSI) 15–65
Water Line Size (NPT) 1/2”
Drain Line Size (NPT) 1 1/2”
ENERGY SPECIFICATIONS
DynaStar
VER/HH-E VER
Latent Heat 6047 Btu/Hr
Sensible Heat 5834 Btu/Hr
ELECTRICAL LOADS
Wash Motor HP (208/230 V) 1
Wash Motor HP (460 V) 3/4
Wash Motor HP (HH-E 208/230 V) 2
Wash Motor HP (HH-E 460 V) 2
Wash Heater kW (208 V) 4.1
Wash Heater kW (230 V) 5.2
Wash Heater kW (460 V) 5.0
Rinse Heater kW (208 V) 9.0
Rinse Heater kW (230 V) 11.2
Rinse Heater kW (460 V) 9.2
