07610-004-43-79-D
6
If water hardness tests at 5 GPG or lower, install the water supply line (1/2” ID pipe
size minimum) to the machine’s incoming water connection point using copper pipe
(or order the 1/2” ID exible hose kit oered by the manufacturer). It is recommended
that a water shut-o valve be installed in the water line between the main supply and
the machine to allow access for service. The water supply line must be capable of a
minimum of 10 PSI “ow” pressure at the recommended temperature indicated on the
data plate.
The manufacturer has an optional water pressure regulator to accommodate areas
where water pressure uctuates or is higher than the recommended pressure. Take
care not to confuse static pressure with ow pressure: static pressure is line pressure in
a “no ow” condition (all valves and services are closed); ow pressure is the pressure
in the ll line when the valve is opened during the cycle.
See the Plumbing Options page.
A shock absorber (not supplied) should be installed on the incoming water line. This
prevents water hammer or hydraulic shock—induced by the solenoid valve as it oper-
ates—from causing damage to the equipment.
See the Plumbing Options page.
The machine has a pumped (pressure) drain capable of pumping waste water to
a height of 24” above the oor to the kitchen’s drain system. Each dishmachine is
supplied with a drain hose. When installed, it will extend from the rear side of the
machine. There must be an air-gap between the machine drain line and the oor sink
or drain at least 1.5 times larger than the drain hose. If a grease trap is required by
code, it should have a ow capacity of 12 GPM.
After installing the incoming ll line and drain line, turn on the water supply to the
machine. Check for any leaks and repair as required. All leaks must be repaired
before operating the machine.
INSTRUCTIONS
INSTALLATION
WATER SUPPLY
CONNECTION:
WATER HARDNESS
OF 5 GPG
OR LOWER
PRESSURE
REGULATOR
SHOCK ABSORBER
CONNECTING THE
DRAIN LINE
Take care not to confuse
static pressure with
ow pressure!
PLUMBING CHECK
1.5x
≤24”
Air-gap
