CAN@net II - Manual, V2.0
Connections and Indicators
12
3.2.3 Ethernet LED (ETH)
The two-color (green and red) LED for Ethernet indicates the Ethernet
communication status of the CAN@net II. For each successfully transmitted
TCP/IP packet, the LED flashes green. In the case of a transmission error, the
LED flashes red.
Flashing mode
Description
Causes/Hints
Off
No Ethernet
communication
possible
• Device unsuccessfully initialized
• Device not connected to Ethernet
• No communication
Green/Green
blinking
TCP/IP packet(s)
transmitted
successfully
• Communication present and
successful
Red/Red
blinking
TCP/IP packet(s)
not transmitted
• TCP/IIP communication not
established, the cable may be
damaged or no network connection
Table 3-6: States of the Ethernet LED
3.2.4 Collision LED (COL)
The yellow LED flashes with each collision detected within the Ethernet traffic.
Flashing mode
Description
Causes/Hints
Off
No collisions
• No collisions in the Ethernet traffic
Yellow/Yellow
blinking
Collision(s)
detected
• Collisions in the network traffic
detected.
Table 3-7: States of the Collision LED
