CAN@net II - Manual, V2.0
Connections and Indicators
11
3.2.1 Power LED (PWR)
The Power LED indicates the status of the power supply. If the LED is green,
the power supply is working. If the LED is off, there is a problem with the power
supply.
Flashing mode
Description
Causes/Hints
Off
No power
• Device not connected to a power supply
• Fuse of the device damaged
• Internal power supply damaged
Green
Power ok
• Device fully functional
Table 3-4: States of the Power LED
3.2.2 Status LED (CPU)
The two-color (green and red) LED indicates the CAN@net II device status.
Flashing mode
Description
Causes/Hints
Off
Device not ready
• Boot manager or application firmware
is not starting
Green blinking
(1 Hz)
Application
firmware started
• Application signals “normal” operating
Green blinking
(2 Hz)
Boot manager
active
• Boot manager of the device is running
• No application on the device or the
application is still not running
Red
Write access to
flash device
• An application is written to the flash
device
• A configuration is written to the flash
device
Red blinking
Device error
• Application or boot manager signals a
device error
Table 3-5: States of the Status LED
