4. For Single View (single monitor) IOGEAR Secure KVM Switch
Using IOGEAR’s proprietary KVM cable set (not supplied with this package and must be purchased
separately), connect the Video connector into any available Video socket in the KVM port section of
the switch, then connect the accompanying USB (Keyboard/Mouse or CAC) and speaker connectors
into their corresponding USB and speaker ports.
For Dual View (dual monitors) IOGEAR Secure KVM Switch,
Using IOGEAR’s proprietary KVM cable set (not supplied with this package and must be purchased
separately), connect the Video connector for primary monitor into any available Video socket A in the
KVM port section of the switch, then connect the accompanying USB (Keyboard/Mouse or CAC) and
speaker connectors into their corresponding USB and speaker ports. Connect a separate Video cable
for secondary monitor to corresponding Video socket B in the same KVM port section of the switch.
Hardware Setup
Note:
1. When the IOGEAR Secure KVM Switch is powered on, the Video LED lights green
indicating that the video connection is established. The Video LED ashes when
non-qualied monitors are connected
2. Due to security policy, IOGEAR Secure KVM Switch does not support monitor hot-
swap. If you would like to change the console monitor, you must rst power off the
entire installation.
3. Connected monitors will be ltered when IOGEAR Secure KVM Switch is powered
on. Non-qualied monitor will be rejected (Video LED ashes). Please refer to the
LED Display for detail visual identication.
Note:
1. Verify that all connectors are in the same or corresponding KVM Port sockets
(all in Port 1, all in Port 2, etc.). Each socket is marked with appropriate icons
2. If the CAC reader function is to be disabled for certain PCs, it is advised not to
connect the corresponding USB CAC cable in the installation
Note:
1. Only speaker connections are allowed. The use of analog microphones or line-in
audio connections is strictly prohibited.
3. Connect the speakers into the console’s speaker jack located on the unit’s front panel.
