44 I-Wave PE953 Installation Guide
Copyright © 2011 Intermatic, Inc.
Problem What to do Reference/Procedure
The circuit breaker
for the pump trips
every time that the
Pump turns ON.
Conrmthatthe
system is programmed
for a 2-speed pump.
1. Press any release any button on the PE953
Hand-held Controller to wake it up.
2. VerifythatthePPE953displays“HISPD1”
or “LO SPD 2” in the upper left hand corner
of the screen.
3. Refer to the illustration on page 9 of this
manual
Check the wiring for a
2-speed pump.
1. Verify that the wire from circuit #1 (PE653
terminal #3) is connected to the High Speed
connection of the pump.
2. Verify that the wire from circuit #2 (PE653
terminal #4) is connected to the Low Speed
connection of the pump.
Conrmthatthe
controls in the heater
are turned ON
1. Verify that the Common connection of the
pump is connected to L2 at the Panel circuit
breaker.
2. Verify that the 2-pole breaker feeding the
PE653 and the Pump is sized correctly.
Problem What to do Reference/Procedure
The heater will not
turn ON.
Go to the Checking
Out and Verifying
section above.
1. Press any release any button on the Hand-
held Controller to wake it up.
2. Note the POOL temperature.
NOTE: The temperature will be shown to the
right of the word POOL in the bottom right
of the PE953 screen.
3. Use the Temperature Set UP arrow to make
the Target temperature setting at least
vedegrees(5º)higherthanthecurrent
temperature.
4. Turn ON the pump.
5. Find and follow the instructions in “Verify
that the Heater is responding to commands
from the PE953 Hand-Held Controller”
printed earlier in this section.
Problem What to do Reference/Procedure
The heater turns
OFF but gets very
hot after the pump
turns OFF.
Verify that the
heater has a proper
“TimeInterval”
programmed for cool
down.
TheFiremanSwitchTimeIntervalisdened
as the additional time the pump will run after
the heater circuit (circuit 5) is turned off to
make sure the heater is cooled down before
it shuts off.
Refer to “Conguring the Fireman’s Switch Time
Interval” starting on page 14 in this manual.
Problem What to do Reference/Procedure
The heater turns
OFF but gets very
hot after the pump
turns OFF.
Verify that the
heater has a proper
“TimeInterval”
programmed for cool
down.
TheFiremanSwitchTimeIntervalisdened
as the additional time the pump will run after
the heater circuit (circuit 5) is turned off to
make sure the heater is cooled down before
it shuts off.
Refer to “Conguring the Fireman’s Switch Time
Interval” starting on page 14 in this manual.
Problem What to do Reference/Procedure
The System will
not respond to
commands from
the Hand-Held
Controller
Verify that the
Antenna section is
properly installed on
the top portion
IftheAntennasectionhasbeenremovedfor
installation of any type of wiring connection,
check the following.
1. Wires are properly wired and routed through
the knockouts in the antenna cover.
2. Verify that all of the local antenna connector
pins on the PE653 art straight and properly
inserting into the plug on the Antenna
section.
3. Verify that the Antenna Section is completely
seated on the PE653 housing.
4. Refer to the “Testing Z-Wave Reception”
section starting on page 18.
Problem What to do Reference/Procedure
Water or moisture
is visible inside the
screen of the Hand-
Held Controller.
Dry out the Hand-
Held Controller.
1. Remove the battery cover on the rear of the
PE953 Hand Held Controller. Refer to page
24 for instructions.
2. Gently drain any water remaining in the
Hand-Held Controller.
3. Place the Hand-Held Controller in a well
ventilated area to dry.
CAUTION: Do not place in direct sunlight.
4. Insertnewbatterieswhenalltracesof
moisture are gone from the screen.
NOTE: Be sure to re-install the gasket correctly
to create a water-tight seal. Refer to page 24
for instructions.
5. Ifrequired,followprogramminginstructions
starting on page 9.
Problem If it doesn’t work Reference/Procedure
The Hand-Held
Controller appears
to be “LOCKED
UP”.
Power down the
Controller to reset.
1. Remove the batteries from the PE953 Hand-
Held Controller.
2. Allow 15 seconds before replacing the
batteries. Refer to page 24 for instructions.
NOTE: Be sure to re-install the gasket correctly
to create a water-tight seal. Refer to page 24
in this manual for instructions.
3. Ifrequired,followprogramminginstructions
starting on page 9.
