Seven: Troubleshooting 43
Providing a brighter solution.™
Problem What to do Reference/Procedure
The 2-speed pump
will not operate in
2-Speed mode
Verify that all wiring
connections are
correct and that all
terminals and splices
are secure.
1. RefertotheWiringInstructionsinSection3
oftheInstallationandUsersGuide.
2. Find the Wiring Diagram that is the most like
the installation starting on page 16 of the
InstallationandUsersGuide.
3. Verify that the system is wired according to
the diagram.
Verify that the correct
voltage is present at
terminals 1 and 2.
1. Use a meter and verify voltage output from
the breaker (should be 240 VAC).
2. Use a meter to verify that the voltage at
terminals 1 and 2 is 240 VAC.
3. Turn ON circuit #1 on the PE653 using either
the Hand-Held controller or the Circuit ON/
OFF switch on the PE653.
4. Use a meter and verify voltage at pump
terminals.
NOTE: L2 must return to the second pole on
the breaker for 240 VAC to be present.
5. Verify that terminal 3 on the PE653 is
connectedtothe‘HIGH’speedterminalat
the pump.
6. Verify that terminal 4 on the PE653 is
connectedtothe‘LOW’speedterminalat
the pump.
7. Verifythatthe‘COMMON’terminalatthe
pump is connected to L2 at the breaker
panel.
Verify that your
systemiscongured
for a 2-speed pump.
8. Refer to “Conguring for a 1-Speed or
2-Speed Pump” starting on page 12.
Contact your pump service company for assistance with the pump.
Problem What to do Reference/Procedure
High speed and low
speed circuits 1 &
2) turn ON together
when the pump is
turned ON.
Conrmthatthe
system is programmed
for a 2-speed pump.
1. Press any release any button on the PE953
Hand-held Controller to wake it up.
2. VerifythatthePPE953displays“HISPD1”
or “LO SPD 2” in the upper left hand corner
of the screen.
3. Refer to the illustration on page 9.
Reprogram for
2-speed pump
operation.
Refer to “Conguring for a 1-Speed or 2-Speed
Pump” starting on page 12.
