Four: Programming for Use with Z-Wave Devices 35
Providing a brighter solution.™
3. Press the button on the Z-Wave device for resetting the device (refer to
themanufacturer’sinstructions).ThescreendisplaysWORKINGfollowed
by SUCCESSFUL. The device is now removed from the network.
4. Press the <ENTER> button if you wish to return to the Main screen.
Setting Up Z-Wave Associations with Capable Devices
An “Association” is a feature supported by certain Z-Wave devices where
Z-Wave device other than the PE953 controller can be used to control other
Z-Wave devices in the network (e.g., a Z-Wave
switch that controls other
Z-Wave
devices).
Within a PE653/953 network, setting up an association with one of these
Z-Wave
devicesmakesitpossibletocontrolCircuit1(thelterpump)of
the PE653 in an ON/OFF basis along with lighting or other features being
controlled by another Z-Wave device, independent of the Hand-Held
Controller.
NOTE: Before you can create an Association, the capable Z-Wave
device
must rst be included in the network.
1. Ifnecessary,pressandreleaseanybuttononthe
Hand-Held Controller to wake it from sleep. If the
screen is not displaying LEARN MODE, press and
hold the <P/S> and <ENTER> buttons at the same
time to put the device into programming mode. You
are in programming mode when the LEARN MODE
screen is displayed, as shown at the right.
2. Press the DOWN button once to display the CNTRL
OPTIONscreen,asshown:
3. Press button <5> toselectSETUPASSOCIATIONS.
The screen displays two choices, as shown:
4. Press button <1> toselectADDDEVICE.Thescreen
addsthewords:PRESSBUTTONONTHEDEVICE
CONTROLLINGTHEASSOCIATIONasshown.This
is the association-capable Z-Wave device you want
to use to control the other devices you plan to add
to the association.
5. Press the button on the device (the same button
used for including the device into a network.
Refertothemanufacturer’sinstructions.)that will
control the association. The screen displays: PRESS
THEBUTTONONTHEDEVICETOADDTOTHE
ASSOCIATION.
