50
8.8.8 Installing and using the Comfort Touch room thermostat
Installation
► Isolate the indoor unit from the mains power and remove the fuse.
► Determine the best internal location ensuring:
1. it is not mounted on an exterior wall
2. it is not subject to any draughts
3. it is not in direct sunlight
4. it is not above any type of heat source
► Please read the supplied installation manual supplied with the
room thermostat, it should be mounted at a height of approximately
1.5 metres from the floor surface. The back plate can be directly
attached to a single wall pattres / back box if required using the
supplied M3 bolts.
► Connect the wires to the terminal block within the thermostat. The
wires push ‘click’ into place.
► Place the thermostat body over the top of the back panel and then
hinge it down.
► Click the housing into place at the bottom.
► Replace the fuse and reestablish the power to the indoor unit..
► The thermostat will start up automatically.
The temperature sensor T43 must be clipped to the heating flow
under the low loss header.
Ensure that the sensor is firmly attached, so that it is in good
contact with the pipework at all times.
To ensure the correct operation of the system, the original supplied
cables and temperature sensors supplied by Intergas must be used.
Place the cables in a suitable duct or conduit to prevent damage.
To enable remote management, the indoor unit must be paired with
the Intergas Gateway.
This consists of a LAN2RF gateway and connection equipment. The
Intergas Gateway connects the appliance to an internet router, aer
which an installer can monitor and manage the appliance remotely
(via a web server) using the Service Dashboard. The end user must
first give permission to the installer to do so, aer the installer has
invited the end user to the Service Dashboard.
When the Intergas Gateway is used, the end user can also use the
Comfort Touch app, which is a thermostat app. The Comfort Touch
app can be downloaded from both the Google Play Store and the
Apple Appstore.
For setting up the Comfort Touch app and a more detailed
description of the app, visit this link:
https://www.intergasheating.co.uk/homeowner/products/
comfort-touch-app/
8.8.9 Comfort Touch app
NOTES
► Please read the user instructions to
operate the Intergas Comfort Touch.
