34 35
NOTES:
• When aiming with the BDC reticle, the ballistic turret can still be
used, and the adjustment of the reticle will become the position
of the aiming point.
• The reticle’s position will not be permanently saved and will
return to the initial position when the function is exited.
• When adjusting the reticle, each click of the Rotary Encoder
represents a real movement of 0.275 MOA (0.93 MIL).
• The ballistic turret will not aect the reticle position data saved in
your Zeroing settings.
28. MAIN MENU OPTIONS AND
DESCRIPTIONS
Menu and submenu options, from left to right are:
• Main Menu: Wi-Fi, Compass, Microphone, Standby, Photo
Setting, Recoil Activated Video, Zeroing Profile, Zeroing, File
Management, Advanced Menu.
• Zeroing Profile Menu: Gun Type, Bullet Type, Shooting
Table, BDC Reticle, Ballistics Solver.
• Zeroing Menu: Preset Zero Distances, Reticle Zeroing, and
Custom Zero Distance.
• Advanced Menu: Video Output, Bluetooth, Status Auto
Hiding, Date and Time, Compass Calibration, Pixel Defect
Correction, Image Hue, Unit, Formatting, Factory Reset, Info.
Menu option details, descriptions, and navigation instructions are
listed in order on the following pages.
Wi-Fi
Main Menu
Settings
Turn Wi-Fi on / o
Turn on Wi-Fi to operate
the scope via the InfiRay
Outdoor App.
1. Long press the
Rotary Encoder to
enter the main menu.
2. Rotate the Rotary
Encoder to select the
Wi-Fi
Main Menu
Settings
menu item.
Wi-Fi is selected by default when the menu is accessed for the
first time.
3. Short press the Rotary Encoder to enter the submenu.
4. Rotate the Rotary Encoder to toggle Wi-Fi on / o. Wi-Fi status, on
or o , changes in real-time and appears in the status bar.
5. Long press the Rotary Encoder to confirm the selection and
return to the home screen.
Compass
Turn the compass and
gravity sensor on / o
1. Long press the
Rotary Encoder to
enter the main menu.
2. Rotate the Rotary
Encoder to select the
compass
menu
item.
3. Short press the
Rotary Encoder to enter the submenu.
4. Rotate the Rotary Encoder to toggle the compass and gravity
sensor on / o. When turned on, the compass appears at the top
of the screen, the pitch angle appears on the right side of the
screen and the tilt angle appears in the lower-right corner.
5. Long press the Rotary Encoder to confirm the selection and
return to the home screen.
Microphone
Turn the microphone
on / o
1. Long press the
Rotary Encoder to
enter the main menu.
2. Rotate the Rotary
Encoder to select the
microphone
menu
item.
3. Short press the
Rotary Encoder to enter the submenu.
4. Rotate the Rotary Encoder to toggle the microphone on / o.
The microphone status, on
or o , changes in real-time and
appears in the status bar.
5. Long press the Rotary Encoder to confirm the selection and
return to the home screen.
