14 15
• Do not expose the battery pack to high temperatures or flames
and do not immerse in water.
• Do not leave the TH50CV2 unattended while charging the
battery pack.
• Do not leave the battery pack charging for long periods after full
charge is reached. Charging time should not exceed 24 hours.
• Keep the battery pack and rifle scope out of the reach of children
and pets.
• The built-in battery pack is equipped with short-circuit protection.
However, any situation that may cause short-circuiting should be
avoided.
• Do not connect the battery pack to any external device with an
electrical current that exceeds permitted levels.
• Do not disassemble, modify, hit, or drop the battery pack.
• Do not connect an external device with a current supply that
exceeds 3.0 USB port.
• Only use compatible 18650, or 18500 and adapter, rechargeable
batteries (not included/optional) in the auxiliary battery
compartment.
To maintain optimal battery capacity and service life:
• Avoid storing a fully charged or discharged battery for long
periods. Partially charging the battery is necessary if the battery
will be stored for an extended period.
• If your TH50CV2 has been stored for an extended period, it
should be charged before initial use.
• Do not charge an extremely cold battery without bringing it into
a warm environment. Let the battery warm up for 45 minutes
before charging.
• Charge the battery at a temperature range from 30°F to 100°F;
otherwise, the service life of the battery may be reduced.
• The recommended operation temperature range is -4°F to 122°F.
Avoid using the battery pack above the maximum or below
the minimum recommended temperature range as this may
decrease the battery pack capacity or service life.
13. EXTERNAL POWER SUPPLY
The BOLT TH50CV2 supports the use of an external power supply,
such as a 5V power bank for a mobile phone. The external power
supply may be used with or without the optional auxiliary battery
installed.
To connect the TH50CV2 to an external power supply:
1. Remove the USB-C port cover (8) by turning it counterclockwise.
2. Connect the smaller USB-C end of the data cable to the USB-C
port (9).
3. Connect the larger USB end of the data cable to the external
power supply. The TH50CV2 will automatically switch to using
the external power supply for power and it will begin charging
the internal battery pack.
a. A charging
icon appears above the battery status
indicator for the built-in battery pack in the bottom-right
corner of the screen, indicating that the battery is charging.
b. The number of bars and color of the battery indicator will
change to reflect the current charge level. See Battery
Status Indicators on page12.
4. When the external power supply is turned o, the TH50CV2 will
switch to the auxiliary battery without turning o.
5. If no auxiliary battery is installed or the auxiliary battery level is
low, the TH50CV2 will switch to the built-in battery pack, instead
of shutting down.
NOTE: Do not connect the TH50CV2 to an external device with a
power supply that exceeds the 3.0 USB cable.
14. MOUNTING THE BOLT TH50CV2
To ensure accurate results, please first properly mount the BOLT
TH50CV2 on your rifle.
The TH50CV2 rifle scope is mounted using traditional 30mm ring
mounts, such as the ring mounts included in the package. Follow the
ring manufacturer’s installation instructions and torque the ring caps
to 20 in/lbs. A torque driver is required to control the torque.
MOUNTING NOTES:
• When mounting the TH50CV2 on a rifle, adjust its position so
that proper eye relief (50 mm) is achieved. Failure to comply with
this recommendation may result in injury to the shooter by the
eyepiece when shooting.
