16 17
• It is recommended to install the TH50CV2 as low as possible for
a proper cheek weld; however, make sure to avoid contact with
the barrel or receiver.
• After mounting, but before hunting with the TH50CV2, zero the
rifle scope. See Zeroing the BOLT TH50CV2 on page22 for
instructions.
15. OPERATING INSTRUCTIONS
WARNING!
Don’t point the objective lens towards any intense energy sources, such as laser radiation or the sun.
This may render the electronic components inoperative. The warranty does not cover damage caused
by improper operation.
Control Features
The BOLT TH50CV2 is operated via four control buttons and a
large metal tactile control turret. The large, easy-to-find control turret
provides audible and tactile feedback when twisted or pressed.
The control buttons can be used to perform shortcut operations from
the home screen, as well as in the menu and full-screen interfaces.
See Description of Control Buttons and Shortcuts on page6 for
shortcut button details.
Powering On / Starting
1. Open the objective lens cap (15).
2. Long press the Power
Button for 2 seconds to power on the
TH50CV2.
To determine the current charge of the built-in battery pack, check
the battery level indicator in the bottom-right corner of the screen.
See Battery Status Indicators on page12.
Powering O / Stopping
To power o the TH50CV2:
1. Press and hold the Power
Button. The standby
screen will open, showing
a 3-second countdown.
2. Continue holding the
Power
Button until
the 3-second countdown
completes.
00:03
Sta n d b y
3. “Data saving...” appears
on the screen and the
TH50CV2 will shut down
automatically after the
data finishes saving.
NOTE: Releasing the
Power
Button at any
time before the countdown
reaches zero will stop the
shutdown process and
the rifle scope will enter
standby mode. Short press
the Power
Button to
exit standby.
WARNING: If using an external power supply, do not disconnect
the power supply when saving data, otherwise the data may not be
saved.
STANDBY MODE
Standby mode may be activated to conserve the battery life of the
rifle scope. When in standby mode, short press the Power
Button
to exit standby and return to the home screen.
Automatically Enter Standby Mode
In the main menu, the TH50CV2 may be set to automatically enter
standby mode after a specified length of inactivity (2, 4, or
6 minutes). See Main Menu > Standby on page37 for detailed
instructions.
1. In the main menu, select the desired standby time, 2, 4, or
6minutes.
2. The standby icon
and status (2min, 4min, 6min, or o) appear
in the top status bar.
3. Once set, the TH50CV2 will automatically enter standby mode,
after the set length of inactivity, to conserve battery life.
NOTES:
• When 2min, 4min, or 6min is selected:
• The TH50CV2 will enter standby mode automatically when
it is tilted up or down at an angle of more than 70° or left or
right at an angle of more than 30°.
• The TH50CV2 will not enter standby mode while it is in a
level position.
• When o is selected, standby mode is turned o and the rifle
scope will operate until the batteries run out.
Da ta Sa v i n g ...
