10. BATTERY STATUS INDICATORS
The status indicator for the
built-in battery pack appears
in the bottom-right corner of
the screen.
If an optional auxiliary battery
is installed in the TH50CV2,
a status indicator for the
auxiliary battery appears in
the bottom-left corner.
The status indicator for the
active battery (the battery
currently being used to power
the TH50CV2) is displayed in
color, while the status
indicator for the inactive
battery is displayed in gray.
Each battery status indicator
has 5 bars which indicate the
current battery charge level.
The color of the indicator bars
for the active battery also
indicates the current charge.
See the table below.
When charging the built-in
battery via the USB-C port,
a charging
icon appears
above its battery status indicator.
Charge the built-in battery pack promptly when it reaches one bar
(5–20%) to avoid over-discharge and potential damage to the battery.
BARS COLORS BATTERY STATUS
5 Bars Green to Blue 81% – 100%
4 Bars Green to Blue 61% – 80%
3 Bars Green to Blue 41% – 60%
2 Bars Yellow to Orange 21% – 40%
1 Bar Orange to Red 5% – 20%; charge the battery promptly
Charging Icon
The built-in battery pack is charging
(external power supply or computer is
connected via the data cable)
11. SWITCHING THE BATTERY
POWER SUPPLY
The BOLT TH50CV2 has a dual power supply system with a built-in
li-ion battery pack and an auxiliary battery option. 18500, or 18650
with adapter, rechargeable li-ion batteries (optional/not included) are
compatible with the TH50CV2.
Using with the Optional Auxiliary Battery
• When both the built-in battery pack and the auxiliary battery
are fully charged, the TH50CV2 will automatically select the
auxiliary battery as its primary power source.
• If the power of the auxiliary battery is low, or the auxiliary battery
is removed, the TH50CV2 will automatically switch to the built-in
battery pack as its primary power supply. Operation will not be
interrupted during this time.
• When the TH50CV2 is in use, you may insert (or replace) an
auxiliary battery without powering o. Power will automatically
switch to the built-in battery during replacement of the auxiliary
battery.
Using with an External Power Source
When the data cable is used to connect the TH50CV2, via the
USB-C port, to a computer or external power source (such as a
standard wall outlet or an external power supply), the rifle scope will
switch to the external power source and begin charging the built-in
battery pack. See External Power Supply on the next page for more
information.
When charging the built-in battery via the USB-C port, a
charging
icon appears above the battery status indicator for the
built-in battery. See Battery Status Indicators on page12.
NOTE: Only the built-in battery pack will be charged while
connected via the USB-C port.
12. BATTERY SAFETY PRECAUTIONS
WARNING: Only use the USB charging/data cable provided in the kit
to charge the built-in battery pack. Only charge the TH50CV2 with
a standard USB adapter (5V–2A), as included in the TH50CV2 kit.
Using any other types of adapters may lead to irreversible damage to
the battery, adapter, or rifle scope. This damage is not covered under
warranty.
WARNINGS:
• Do not use a power adapter or USB cable that has been
modified or damaged.
