6. Operation

6.1. Safety Instructions for Operation

Attention

This device must be used only for the purposes it is designed for.

This device is intended for professional use as a moving head. It can be installed indoors and outdoors. This

device is not suitable for households and for general lighting.

Any other use, not mentioned under intended use, is regarded as non-intended and incorrect use.

Attention

Power supply

Before connecting the device to the power supply, make sure that the current, voltage and frequency match

the input voltage, current and frequency specified on the information label on the device.

6.2.

Control Modes

The Furion W402 WashBeam supports the following control modes:

• Stand-alone: Stand-alone mode (built-in programs), manual control•

• DMX-512: Basic (14 channels), Advanced (22 channels), User (22 channels)•

• WDMX: Basic (14 channels), Advanced (22 channels), User (22 channels)•

• Art-Net: Basic (14 channels), Advanced (22 channels), User (22 channels)•

• sACN: Basic (14 channels), Advanced (22 channels), User (22 channels)•

For more information about how to connect the devices, refer to Setup (see 5. Setup on page 18).

To operate the device manually as a stand-alone device:

Adjust the parameters of the device in the Manual Control menu (see 6.7.5. Manual Control on page 40).

To run the built-in programs in auto operation mode without a DMX controller:

Select the control mode of the device in the Stand Alone menu (see 6.7.3. Stand Alone on page 39). If you

select Program 1–9, the device will run the built-in program.

To operate the device with a DMX controller:

01) Select DMX512 as control mode in the Control Mode menu (see 6.7.4. Control Mode on page 39).01)

02) Set the DMX starting address of the device in the DMX Address menu (see 6.7.1. DMX Address on page02)

31).

03) Select the DMX channel mode in the Control Mode menu (see 6.7.4. Control Mode on page 39). Refer to03)

DMX Channels (see 6.8. DMX Channels on page 44) for a complete overview of all DMX channels.

To operate the device wireless with a DMX controller in combination with a wireless transceiver:

01) Select WDMX as control mode in the Control Mode menu (see 6.7.4. Control Mode on page 39).01)

02) Set the DMX starting address of the device in the DMX Address menu (see 6.7.1. DMX Address on page02)

31).

03) Select the DMX channel mode in the Control Mode menu (see 6.7.4. Control Mode on page 39). Refer to03)

DMX Channels (see 6.8. DMX Channels on page 44) for a complete overview of all DMX channels.

To operate the device via Art-Net with a computer/lighting controller:

01) Select ArtNet as control mode in the Control Mode menu (see 6.7.4. Control Mode on page 39).01)

02) Set the DMX starting address of the device in the DMX Address menu (see 6.7.1. DMX Address on page02)

31).
