19
Electrical Connection
All electrical connections must be made by a suitably
qualified and licensed person in accordance with local
regulations. Residentia Group will not be held responsible for
damages caused to cabinetry due to incorrect installation.
Those ovens equipped with a three-pole power supply cable
are designed to operate with an alternating current. The wire
for earthling the appliance is yellow-green in colour.
Fitting on a Power Supply Cable
Opening the terminal board:
• Using a screwdriver, prize the bolt on the side tabs
of the terminal board cover;
• Unscrew the bolt, pull open the cover
of the terminal board.
To install the cable, proceed as follows:
• Remove the wire clamp screw and the three contact
screws L-N-
• Fasten the wires beneath the screw heads using the
following colour scheme:
Blue (N) Brown (L) Yellow-Green
• Fasten the supply cable in place with the clamp and close
the cover of the terminal board.
Connecting the supply cable to the mains
• Install a standardized plug corresponding to the load
indicated on the data plate. When connecting the cable
directly to the mains, install an omni polar circuit breaker
with a minimum contact opening of 3mm between the
appliance and the mains. The omni polar circuit breaker
should be sized according to the load and should comply
with current regulations (the earth wire should not be
interrupted by the circuit breaker).
• The supply cable should be positioned so that it
does not reach a temperature of more than 50°C with
respect to the room temperature, anywhere along its
length, or protected by insulation sleeping having an
appropriate rating.
Before making the connection, check that:
• The electrical safety of this appliance can only be
guaranteed if the cooker is correctly and eciently
earthed, in compliance with regulations on electrical
safety. Always ensure that the earthling is ecient;
if you have any doubts call in a qualified technician
to check the system. The manufacturer declines all
responsibility for damage resulting from a system
which has not been earthed.
• Before plugging the appliance into the mains, check that
the specifications indicated on the date plate (on the
appliance and /or packaging) correspond to those of the
electrical mains system of your home.
• Check that the electrical capacity of the system and
sockets will support the maximum power of the appliance,
as indicated on the data plate. If you have any doubts,
call in a qualified technician.
• If the socket and appliance plug are not compatible, have
the socket replaced with a suitable model by a qualified
technician. The latter, in particular, will also have to
ensure that the cross section of the socket cables are
suitable for the power absorbed by the appliance. The use
of adapters, multiple sockets and/or extensions, is not
recommended. If their use cannot be avoided, remember
to use only single or multiple adapters and extensions
which comply with current safety regulations. In these
cases, never exceed the maximum current capacity
indicated on the single adapter or extension and the
maximum power indicated on the multiple adapter.
The plug and socket must be easily accessible.
Voltage and Frequency of Power Supply:
220-240V ~50/60Hz or 50Hz
Installing Your Oven (Continued)
