14
INSTRUCTIONS FOR USE
Operation
- Fridge zone temperature setting range: 2°C -8°C;
- Freezer zone temperature setting range: -15°C--23°C;
- FLEX zone temperature setting range: -4°C ,0°C and 4°C ;
- Default set temperature for initial power-on: Fridge zone -5°C, freezer zone -18°C and
FLEX zone - 0°C;
- ULTRA FREEZER button: The ULTRA FREEZER mode will be enabled by touching this
button, and the icon above this button will be On;
- Under the ULTRA FREEZER mode, the set temperature shown on the display does not
change, however the temperature of the freezer zone will decrease continuously;
- The ULTRA FREEZER mode can be exited aer a continuously running for 2hrs or when
the temperature of the freezer zone sensor is below -35°C or when the button is touched
again, and the icon above this button will be O.
- QUICK FREEZER button: The QUICK FREEZER mode will be enabled by touching this
button, and the icon above this button will be On;
- Under the QUICK FREEZER mode, the set temperature shown on the display does not
change, however the temperature of the freezer zone will decrease continuously;
- The QUICK FREEZER mode can be exited aer a continuously running for 24hrs or when
the temperature of the freezer zone sensor is below -28°C or when the button is touched
again, and the icon above this button will be O.
- Freezer zone button: By touching this button, the icon above it will be On and the freezer
zone temperature setting will be allowed;
- Temp.adjust button(-): Aer allowing the temperature setting of the freezer zone, FLEX
zone or fridge zone, the corresponding set temperature will decrease by 1°C by touching
this button each time, which will not work when reaching the minimum temperature;
- Temp.adjust button(+): Aer allowing the temperature setting of the freezer zone, FLEX
zone or fridge zone, the corresponding set temperature will increase by 1°C by touching
this button each time, which will not work when reaching the maximum temperature;
- Fridge zone button: By touching this button, the icon above it will be On and the fridge
zone temperature setting will be allowed;
- FLEX zone button: By touching this button, the icon above it will be On and the FLEX zone
temperature setting will be allowed;
- Quick cool zone button: The quick cool mode will be enabled by touching this button, and
the icon above this button will be On;
Feature selection &
temperature settings
Control panel
(-)
(+) (-) (+)
Temp.
adjust button
Temp.
adjust button
Lock button
Temp.
adjust button
Temp.
adjust button
Ultra freezer
button
Quik freezer
button
Freezer
zone button
Fridge
zone button
Flex
zone button
Quick cool
zone button
