Condition monitoring sensor with CANopen interface VMB301
21
Index Subindex
Name
(Object)
Type Access Default value
PDO
Mapping
capability
Save object
value
0x2051 0x00 Selection
Measurement ax-
es
Velocity
u8 rw 7 (xyz axis) Yes
0x2052 0x00 Selection
Measurement axis
Displacement
u8 rw 3 (z axis) Yes
0x2053 0x00 Selection of analy-
sis measurement
axis
u8 rw 3 (z axis) Yes
0x2054 Rolling bearing frequency factors
0x01 Inner race r32 rw 0.0 Yes
0x02 Outer race r32 rw 0.0 Yes
0x03 Rolling r32 rw 0.0 Yes
8.7.2 Bus configuration
Index Subindex
Name
(object)
Type Access Default value
PDO
Mapping
capability
Save object
value
0x20f0 0x00 NodeID A u8 rw 42 Automatically
saved
0x20f1 0x00 NodeID B u8 rw 42
0x20f2 0x00 Baud rate A u8 rw 3
0x20f3 0x00 Baud rate B u8 rw 3
0x20f4 0x00 CAN
120 Ω resistor
u8 rw 0
0x20f5 0x00 LED indicator u8 rw 0
8.7.3 Extended sensor functions
Index Subindex
Name
(object)
Type Access Default value
PDO
Mapping
capability
Save object
value
0x4000 0x00 Reset
microcontroller
u8 wo 0 -
0x4001 Identification
0x01 Installation date String rw yyyy-mm-dd -
0x02u Installation loca-
tion
String rw Installation lo-
cation
-
0x4002 MEMS self-test
0x01 Activate
self-test
u8 wo 0 -
0x02 Self-test
Register
u8 ro 0xfc -
0x4003 Raw acceleration data
0x01 Raw data
acceleration data
u8 rw 0 (xyz axis -
every 4s)
- Yes
0x02 Recording raw da-
ta
u8 wo 0 -
0x03 Raw data
Availability
u8 ro 0 -
