VMB301 Condition monitoring sensor with CANopen interface
20
Index Subindex
Name
(object)
Type Access Default value
PDO
mapping
capability
Save object
value
0x1a02 0x05 Mapping Entry 5 u32 0x0000 - Yes
0x06 Mapping Entry 6 u32 0x0000 - Yes
0x07 Mapping Entry 7 u32 0x0000 - Yes
0x08 Mapping Entry 8 u32 0x0000 - Yes
0x1a03 TPDO 4 Mapping Parameter -
0x01 Mapping Entry 1 u32 0x0000 - Yes
0x02 Mapping Entry 2 u32 0x0000 - Yes
0x03 Mapping Entry 3 u32 0x0000 - Yes
0x04 Mapping Entry 4 u32 0x0000 - Yes
0x05 Mapping Entry 5 u32 0x0000 - Yes
0x06 Mapping Entry 6 u32 0x0000 - Yes
0x07 Mapping Entry 7 u32 0x0000 Yes
0x08 Mapping Entry 8 u32 0x0000 Yes
0x1a04 TPDO 5 Mapping Parameter
0x01 Mapping Entry 1 u32 0x0000 - Yes
0x02 Mapping Entry 2 u32 0x0000 - Yes
0x03 Mapping Entry 3 u32 0x0000 - Yes
0x04 Mapping Entry 4 u32 0x0000 - Yes
0x05 Mapping Entry 5 u32 0x0000 - Yes
0x06 Mapping Entry 6 u32 0x0000 - Yes
0x07 Mapping Entry 7 u32 0x0000 Yes
0x08 Mapping Entry 8 u32 0x0000 Yes
0x1f51 Program Control
0x01 Program Control u8 rw 1 -
0x1f80 0x00 NMT startup u32 rw 0 - Yes
8.7.1 Parameter setting of the vibration monitoring
Index Subindex
Name
(Object)
Type Access Default value
PDO
Mapping
capability
Save object
value
0x2020 0x00 Machine speed u16 rww 3000 Optional as
RPDO
Yes
0x2040 0x00 Filter DC u8 rw 1
10 Hz high
pass
Yes
0x2041 0x00 Filter
Acceleration indi-
cators
u8 rw 0 (no filter) Yes
0x2042 0x00 Filter speed indi-
cator
u8 rw 0 (1000 Hz
low-pass)
Yes
0c2043 0x00 Filter displace-
ment indicator
u8 rw 0 (100 Hz
low-pass)
Yes
0x2050 0x00 Selection
Measurement ax-
es
Acceleration
u8 rw 7 (xyz axis) Yes
