SU2x5x SU6x5x SU7x5x SU8x5x SU9x5x Ultrasonic flow meter
22
MEWMAW AEPASP
4
3,80,45
3,50,25
FOU=OFF
20
20,5
0,5
4,5
4,63
[mA][V]
cr.UL UL OL cr.OL
2
3
4
1
B
A
21,54,9
FOU=On
-120Q [% MEW]
[°C]T -48 -40 120 144 156
-130
-52
[°F]-54,4 -40 248 291,2 312,8-61,6
1201000 130
Fig.9: Characteristic of the analogue output according to IEC 60947-5-7. [I / 4…20 mA]; [U / 0.5…4.5 V]
B
A
MEWMAW AEPASP
-120Q [% MEW]
[°C]T -48 -40 120 144 156
-130
-52
[°F]-54,4 -40 248 291,2 312,8-61,6
1201000 130
FOU=OFF
0
10
10,3
[V]
cr.UL UL OL cr.OL
2
3
4
1
11
FOU=On
Fig.10: Characteristic of the analogue output according to IEC 60947-5-7. [U / 0…10 V]
A: Analogue signal MAW: Initial value of the measuring range
B: Process value MEW: Final value of the measuring range
1: Detection range ASP: Analogue start point
2: Indicating range AEP: Analogue end point
3: Measuring range UL: Below the indicating range
4: Scaled measuring range cr.UL: Below the detection range
Q: Flow OL: Above the indicating range
T: Temperature cr.OL: Above the detection range
