Ultrasonic flow meter SU2x5x SU6x5x SU7x5x SU8x5x SU9x5x
21
Parameters to be set:
[oux] = [ImP]; [ImPSx]; [ImPRx] = [no]
9.2.3.2 Pulse signal totaliser
Pulse signals can be provided for consumed quantity monitoring.
Every time the consumed quantity (pulse value) set under [ImPS] has been reached, the output
provides a pulse signal.
The pulse signal consists of a short switching on and off of the output.
Pulse signals are not available via the IO-Link interface.
Parameters to be set:
[oux] = [ImP]; [ImPSx]; [ImPRx] = [yes]
9.2.4 Analogue signal
The device provides an analogue signal proportional to the process value.
The analogue signal can be provided as current or voltage signal.
Within the measuring range, the analogue signal is in the following range depending on the parameter
setting:
• Current output: 4...20 mA
• Voltage output: 0.5…4.5V or 0...10V.
The measuring range is scalable: the parameters [ASP] and [AEP] allow for the measuring range to be
limited.
• [ASP2] determines at which measured value the output signal is 4mA or 0.5V or 0V.
• [AEP2] determines at which measured value the output signal is 20mA or 4.5V or 10V.
Minimum distance between [ASP2] and [AEP2] = 20 % of the final value of the measuring
range.
If the measured value is outside the measuring range or in the event of an internal error, the current or
voltage signals indicated in the following figure are provided.
