Ultrasonic flow meter SU2x5x SU6x5x SU7x5x SU8x5x SU9x5x
23
A negative flow value means flow against the flow direction set under [Fdir]. See Flow direction.
The [FOU] parameter can be used to set the behaviour of the analogue output in the event of an error
Ò chapter Error behaviour of the outputs.
Parameters to be set:
[ou2] = [I/4…20mA], [U/0.5…4.5V], [U/0…10V]; [ASP2]; [AEP2]
9.2.5 Frequency signal
The device provides a frequency signal proportional to the process value.
The frequency signal is scalable:
• [FrPx] defines the frequency signal in Hz that is provided when the upper measured value is
reached.
The measuring range is scalable:
• [FSPx] defines the lower measured value from which a frequency signal is provided.
• [FEPx] defines the upper measured value at which the output signal has the frequency set under
[FrPx].
[FSPx] is only available for temperature measurement. Minimum difference between [FSPx] and
[FEPx] = 20 % of the final value of the measuring range.
If the measured value is outside the measuring range or in the event of an internal error, the frequency
signal indicated in the following figure is provided.
