Encoder (SR) with CANopen interface RM900S RM901S RM902S RM903S
23
Safety classification
Meets the requirements of IEC 61508 SIL 2
IEC 61800-5-2
IEC 61800-5-3
EN ISO 13849-1 PL d Cat.3
Mission Time (TM) [h] 175800
Mission time TM (additional indication) (20 years)
PFH [1/h] 2,00E
-8
Mechanical data
Dimensions [g] Ø 58 / L = 98.8
Materials Flange: aluminium; Housing: Aluminium;
Seals: NBR / HNBR; Display: polycarbonate; Connections (axial): Diecast
zinc, nickel-plated;
Connections (radial): nickel-plated brass
Max. revolution mechanical [rpm] 6000
Max. starting torque [Nm] 5
Tightening torque reference tempera-
ture
[°C] 20
Max. axial shaft load (10 mm from
flange)
[N] 80 @ 3000 min
-1
40 @ 6000 min
-1
Max. radial shaft load (10 mm from
flange)
[N] 100 @ 3000 min
-1
50 @ 6000 min
-1
Shaft material 1.4305 (stainless steel / 303)
Angular acceleration [rad/
s
-2
]
≤ 1*10
4
Bearing service life Lnmr 3.6*10
10
U
(6000 min
-1
;
60 °C; 40 N axial / 50 N radial)
Lnmr 3.9*10
9
U
(6000 min
-1
;
60 °C; 80 N axial / 100 N radial)
8.1 Functional safety
The attainable Safety Integrity Level or Performance Level depends on the device and is noted on the
type label.
EN ISO 13849-1: 2023, performance level PLd / Cat. 3
8.2 Power supply
u Only operate the encoder on power supply units in accordance with the requirements of SELV/
PELV (IEC 60364-4-41:2005).
u In UL applications, only operate the encoder on NEC Class 2 power supply units.
Nominal voltage 24 V DC
Power consumption ≤ 6 watts
