RM900S RM901S RM902S RM903S Encoder (SR) with CANopen interface
22
Interfaces
Number of CAN interfaces 2
Transmission rate 20 kBits/s... 1 Mbit/s
Terminating resistor yes; (external M12)
CAN
Protocol CANopen; CANopen safety; CAN specification 2.0 A
Factory settings Baud rate: 250 kBits/s
Node ID: 32
Version CiA 406 V4.1.0; CiA 301 V4.2.0; CiA DSP-305 V3.0.0 LSS; EN 50325-4;
EN 50325-5; EN 11898
Environmental conditions
Ambient temperature [°C] -40...85
Derating operating temperature The permissible operating temperature is reduced by the specified factor
depending on the speed n:
T
A
= -0.004 * n + 85° C (IP67)
The operating temperature must be taken into account to allow for internal
heat generation when the shaft is rotating.
Storage temperature [°C] -40...90
Note on storage temperature dry
Max. permissible relative humidity [%] 98
Max. height above sea level [m] 5000
Protection rating IP67, IP 69K; (with ifm socket duly screwed on)
Approvals / tests
EMC IEC 61000-4-2 ESD 6 6 kV CD / 15 kV AD
IEC 61000-4-3 HF radiated: 20 V/m (27…1000 MHz)
10 V/m (1000…2000 MHz)
3 V/m (2000…6000MHz)
IEC 61000/4/4 Burst 4 kV
IEC 61000-4-5 Surge 2 kV (screen)
IEC 61000-4-6 HF 20 V
IEC 55011 Class B
IEC 61000-4-8 magnetic fields 30 A/m (50 Hz) /
1000 A/m (0 Hz)
Criterion A from any direction
Vibration resistance IEC 60068-2-64 15 g; Sinus; (50...2000 Hz)
ISO 19014-3 5.7 g; RMS
Shock resistance IEC 60068-2-27 100 g 6 ms half-sine;
100 shocks each in every direction of the 3
coordinate axes
Standard compliant with ECE R 10 Rev.6
Salt spray test IEC 60068-2-52 Severity level 5
Comment Can be used in applications up to
• SIL 2 in accordance with IEC 62061
• Ag PL d in accordance with ISO 25119
• MPL d in accordance with ISO 19014-3
