Electronic manometer PG17xx
© ifm electronic gmbh 11601190 / 01 07 / 2025 37
11.3.1.2 Teach via device keys: Switching signal
Switching signal channel SSC1.1 is set using the device keys. Further switching signal chan-
nels can be set via the IO-Link interface.
The standard unit of measurement is selected: EF > CFG > uni.P.
Switching channel SSC1.1 is selected for output 1: EF > OU1 > ou1 = SSC1.
Go to EF > OU1 to configure output OUT1.
Single point mode:
Select ModE and set the switch-point mode: 1-P.
Approach the system pressure at which the output is to switch and keep it constant.
Select tSP1 and set Yes.
The current value minus the hysteresis is adopted as switch point SP1.
Select HYSt and set the hysteresis.
Two-point mode:
Select ModE and set the switch-point mode: 2-P.
Approach the system pressure at which the output is to switch and keep it constant.
Select tSP1 and set Yes.
The current value is adopted as switch point SP1.
Approach the system pressure at which the output is to reset and keep it constant.
Select tSP2 and set Yes.
The current value is adopted as switch point SP2.
Window mode:
Select ModE and set the switch-point mode: WInd.
Select HYSt and set the hysteresis.
Approach the system pressure for the upper limit of the window section and keep it constant.
Select tSP1 and set Yes.
The current value is adopted as switch point SP1.
Approach the system pressure for the lower limit of the window section and keep it constant.
Select tSP2 and set Yes.
The current value is adopted as switch point SP2.
If an invalid measured value outside the measuring range is using for teaching, UL or OL and
FAIL are displayed alternately. The value is not adopted.
11.3.2 Analogue signal
The device provides an analogue signal proportional to the process value.
Within the measuring range the analogue signal is between 4...20 mA.
The analogue signal is invertible:
• 4...20mA for setting ou2 = I
• 20...4mA for setting ou2 = InEG
