Electronic manometer PG17xx
© ifm electronic gmbh 11601190 / 01 07 / 2025 13
ATTENTION
If the sensor is screwed too tightly into the adapter.
The seal of the process connection will be impaired.
Use a torque wrench.
Do not exceed the tightening torque of 35 Nm.
6.2.1 Process adapter with sealing ring (hygiene-compliant to 3-A and
EHEDG)
To meet the hygiene regulations use a process adapter with leakage port.
The process adapters are supplied with an EPDM O-ring.
More sealing rings are available as accessories:
• FKM O-ring (only for 3-A)
• PEEK sealing ring
– The PEEK sealing ring is long-term stable and maintenance-free.
– When replacing the PEEK sealing ring or when changing from the PEEK sealing ring to an O-ring:
Replace the process adapter with a new equivalent process adapter.
Use for 3-A marked and EHEDG certified clamp designs to ISO2852 and DIN32676 in combination
with Combifit sealing.
Information about available accessories at www.ifm.com
6.2.2 Welding adapter with sealing ring (hygiene-compliant to 3-A and
EHEDG)
To meet the hygiene regulations use a process adapter with leakage port.
The welding adapter is supplied with an EPDM O-ring.
An FKM O-ring is available as accessory (only for 3-A).
Information about available accessories at www.ifm.com
CAUTION
Welding work
Risk of injury due to improper welding of the adapter.
Ensure that welding is performed by qualified personnel according to the state of the art.
Observe the installation instructions of the welding adapter used, in particular the warning
and safety information provided in these instructions (
download at
documentation.ifm.com
).
